User Safety Instructions - Bellcome 2 smart Benutzerhandbuch

An additional
Terminal is mounted
in the system.
The system is
6
functioning; one of
the Terminals cannot
be called (the Main
Terminal, or the
Additional Terminal)
An Additional
Terminal is mounted
in the system.
The system is
7
functioning; on the
additional Terminal,
the image is "noisy".
USE
7

7.1 User safety instructions

Do not hit the glass screen with hard objects!
If the front glass screen cracks, DO NOT touch the product!
7.2 Use of the video Terminal
1
The keyboard is not backlit.
By successive touches of this key, the following states of the Terminal are achieved: ON
(white LED), and turned OFF (red LED). The red LED will remain permanently turned on
until the key is touched again.
Stand-by
By touching this key, you may see what goes on at the entrance, in front of the outdoor
panel. For audio monitoring or communication, touch also the Communication key
During call or monitoring, by touching the MENU key
be made. ( see S7. Screen and volume adjustments).
Touch the monitoring key to exit monitoring mode. Otherwise, monitoring will stop after
First touch of
the time set in the settings menu ( see S2. Ring tone and monitoring settings).
Monitoring can be also accessed by selecting the
Menu. (see S1. How to enter the MAIN MENU Page).
By touching the space between the keys
Power supply:
GREEN LED
Outdoor panel:
The key and the name of the
inhabitant are backlit
Terminal:
The keyboard lights up when
touched
Power supply:
GREEN LED
Outdoor panel:
The key and the name of the
inhabitant are backlit
Terminal:
The keyboard lights up when
touched
STAND-BY
TURN TERMINAL ON/OFF
At the first touch of the ON/OFF key the 4 keys
AUDIO – VIDEO MONITORING
Monitoring duration: 30 s, 40 s, 50 s, 1 min, 2 min, 3 min, 5 min, 10 min.
SETTINGS
light up.
Both terminals have
address 1.
Both Terminals have the
internal jumpers set up
for end of line.
, image and sound adjustments can
icon in the MAIN SETTINGS
the keys for the SETTINGS menu
Set up address 2 for the
additional terminal, from
the SETTINGS menu (ch.
7.2 Use of the video
Terminal , pt. S4. Slave
Adress)
Set up the jumpers
according to ch. 5.1
Parallel connection of an
additional Terminal
get lit up.
.
12/16
