Keyboard
Display of the inhabitant's name
Command of an
electromagnetic lock (DC or AC)
Command of an
auxiliary automation (DC or AC)
Case
Mounting
Casing protection level (IP)
Operating temperature range
Transport and storage
temperature range
Dimensions
Weight
2.2 Technical features of the video Terminal
Power supply
Display
Keyboard
Adjustments
Case
Mounting
Casing protection level (IP)
Operating temperature range
Range of transport and storage
temperatures
Dimensions
Weight
TOUCH type, permanently backlit
Backlit name space
Relay contact
Maximum switched current 1 A
Relay contact
Maximum switched current 1 A
Aluminum profile painted in electrostatic field;
Secured glass screen, 8 mm thick
Flush
IP44
- 30° C ... + 60°C
- 33° C ... + 55° C
294 x 144 x 53 mm
1,4 kg ± 0.01 kg
26 ... 30 V DC (stabilized)
3.5" LCD, TFT, resolution: 320 x RGB x 240;
Display Up/down/right/left visibility angle: 10/35/50/50
TOUCH type, 10 keys with backlight on touch
Permanent RED signaling of the ON-OFF key if the
terminal is turned off.
Continuous adjustment of the audio communication
volume;
Image adjustments: luminosity, chrominance;
ABS
Glass screen, 4 mm thick
Surface / Flush
IP31
0°C ... + 45°C
- 33°C ... + 55°C
237 x 122 x 25 mm
0,6 kg ± 0.01 kg
