INSTALLATION OF THE CAR SEAT WITH CONNECTORS

The saftey of your child will be increased using the ISOFIX-
CONNECT system linking the child seat tightly with the vehicle.
your child will still be buckled up using the car's 3-point-belt.
• Connect the two enclosed X-fi x installation aids (their longer parts pointing
upwards) with the two isofiX anchorage points (i).
Note! The car's isofiX anchorage points (i) are two metal rings per seat,
located between the backrest and the seat cushion of your vehicle seat.
If in doubt please refer to your vehicle owner's manual.
• For adjustment move the X-fi x lever (v), located on the bottom of the seat.
• Pull the connectors (w) as far out as they will go.
• Rotate the X-fi x connectors by 180° until they point into the direction of the
installation aids.
Note! Make sure that the green safety indication (x) of the connectors
is not visible. If necessary, release them by pushing and simultaneously
pulling back the red release button (y). Repeat this procedure with the
other connector.
• Push both of the X-fi x connectors (w) into the installation aids until you hear
them clicking into the isofiX anchorage points (i).
• Make sure that the child seat is connected safely by trying to pull it out.
• The green safety indication (x) must be clearly visible on both sides of the red
release buttons (y).
• With the X-fi x button located on the bottom of the child seat you can now
adjust the position of the seat.
Note! For additional information please refer to the section "Placing the
Seat in the Car".
• You can now buckle up the child. Please refer to "Buckling Up the Child".
