Changing the speed mode from 5 to 10 minutes

1 Press and hold the RECORD button.
2 Tap the FLASH button 5 or 10 three times while holding down the RECORD button.
3 The 5 MIN or 10 MIN LED should light up indicating the Speed fader is set to run in the 5 or 10 minute mode.

Reverse the direction of chase programs

1 Reverse the direction of all the scenes. Press the ALL REV Button, all scenes should change their directions.
2 Reverse the chasing direction of all programs currently running: Press the CHASE REV button.
3 Reverse the chasing direction of all the programs with memorized standard speed: Press the BEAT REV
button.
4 Reverse chasing direction of a particular program. Press and hold down the REV ONE button, then press
down the FLASH button corresponding to your desired program and release together.

Fade time

1 The fade time is the amount of time that it will take for the dimmer to go from zero output to maximum output,
and vice versa.
2 Fade time is adjusted through the Fade Fader, which varies from instant to 10 minutes.

TAP SYNC button

1 Be sure the Sound control mode is disengaged. The Audio LED is off.
2 The TAP SYNC button is used to set and synchronize the chase rate (the rate at which all scenes will
sequence) by tapping the button several times. The chase rate will synchronize to the time of the last two taps.
The LED above the STEP button will flash at the new chase rate. The chase rate may be set anytime whether
or not a program is running.
3 Tap TAP SYNC will override any previous setting of the speed fader control until the fader is moved again.

Master fader

1 The Master fader control provides proportion level control over all channels and scenes with the exception of
the Flash Buttons.
2 For example: Whenever the Master fader control is at minimum, all stage outputs will be at zero except for any
resulting from a FLASH button or FULL ON button. If the Master is at 50%, all outputs will be at only 50% of the
setting of current channel or scenes except for any resulting from a Flash button or FULL ON button. If the
Master is at full, all outputs will follow the unit setting.
3 Master fader A always controls outputs of channels 1-12. Master fader B controls the programs or scenes
except in Double Preset mode.

Single mode

1 All chase programs will run in sequential order starting in the order of program number.
2 The display will read the running program number.
3 All programs will be controlled by the same Speed Fader.
4 Press the MODE SELECT button and select CHASE/SCENES mode.
5 Press the PARK button to select SINGLE CHASE mode. A red LED will indicate this selection.

Mix mode

1 All chase programs will run synchronously.
2 All programs can be controlled by the Speed Fader or each program's speed may be controlled individually
( section Running a program with a standard speed).
3 Press the MODE SELECT button and select CHASE/SCENES mode.
4 Press the PARK button to select MIX CHASE mode. A red LED will indicate this selection.

GENERAL FUNCTIONS
