Running chase programs

1 Tap the MODE SELECT button to select CHASE/SCENES mode indicated by the red LED.
2 Tap the PAGE button to select the correct page the program you wish to run is located.
3 Push Master Fader B to its maximum position (fully down).
4 Move the desired Channel fader (13-24) to its maximum position to trigger the program, and the program will
fade in depending upon current fade time.
5 You may also hold down the respective FLASH button to trigger the program.
6 Move the Channel fader to adjust the output of the current program.
7 Multiple programs can be selected at a time. Simply move multiple channel faders or hold down the respective
FLASH buttons to trigger the desired programs.
8 Use the PARK button to switch between SINGLE CHASE mode and MIX CHASE mode.
• SINGLE CHASE LED lights: All chase programs will run in sequential order.
• MIX CHASE LED lights: All chase programs will run synchronously.

Sound control

1 Use the built-in microphone or plug an audio source into the RCA audio jack.
2 Select your program as described above.
3 Tap the AUDIO button until its LED lights, indicating Sound control mode is active.
4 Use the AUDIO LEVEL fader to adjust the music sensitivity.
5 To return to normal mode, tap the AUDIO button a second time causing its LED to go out. The Sound control
mode is disengaged.

Running a program with a standard speed

You can define and memorize a standard speed for every chase program.
1 Be sure the Sound control mode is disengaged. Tap the MODE SELECT button to select CHASE/SCENES
mode.
2 Tap the PARK button to select MIX CHASE mode. The LED lights indicating this selection.
3 Select your program as described above.
4 Move the SPEED fader until the display reads your desired value. You may also tap the TAP SYNC button
twice to define your speed.
5 While pressing and holding down the REC SPEED button, tap the FLASH button (13-24) that stores the
program.
6 The program will then run with the set speed when engaged.
7 Repeat steps 4 and 5 to set a new speed.
.
NOTE
Programs with memorized standard speed do not react to manual speed settings or Sound control mode.

Deleting a memorized standard speed

1 Be sure the Sound control mode is disengaged. The Audio LED is off.
2 Select your program as described above.
3 Move the Speed fader to the SHOW MODE position. Then tap the FLASH button (13-24) while pressing and
holding down the REC SPEED button. The corresponding program will not run with the standard speed any
longer.
4 Now you may move the Speed fader to select your desired speed.
