EuroLite DMX Scene Setter 24/48 Bedienungsanleitung Seite 22

No. Element
1 PRESET A indicators
2 Channel faders 1-12
3 Flash buttons 1-12
4 PRESET B indicators
5 SCENE indicators
6 Channel faders 13-24
7 Flash buttons 13-24
8 BLIND button
9 HOME button
10 TAP SYNC button
11 FULL ON button
12 BLACK OUT button
13 MASTER A fader
14 MASTER B fader
15 FADE fader
16 SPEED fader
17 AUDIO LEVEL fader
18 MASTER A button
19 PARK button
20 HOLD button
21 STEP button
22 AUDIO button
23 DARK button
24 MODE SELECT button
25 PAGE/REC CLEAR button
Function
Show the current intensity of the channels 1-12.
For adjusting the DMX values of channels 1-12 for the connected DMX
fixtures.
These 12 buttons are used to bring an individual channel (1-12) to full
intensity (255).
Show the current intensity of the channels 13-24.
Light up when corresponding scenes are active.
For adjusting the DMX values of channels 13-24 for the connected DMX
fixtures.
These 12 buttons are used to bring an individual channel (13-24) to full
intensity (255).
This function takes the channel out of the program in CHASE/SCENE
mode.
This button is used to deactivate the Blind function.
Press this button twice to adjust the running speed of the chase program.
When activated, all channel outputs will be set to maximum (255) and
blackout mode is disabled. This button is ideal for testing if a DMX signal
is fed to the DMX fixtures.
Sets all control channels to the value zero regardless of the FULL ON
button. The corresponding LED is flashing. Thus, it is possible to blackout
e. g. all DMX fixtures. As a basic setting, the Blackout function is activated
when switching on.
This fader controls overall output of channels 1-12 (Preset A).
This fader controls the scenes/chases in Chase/Scene and Single Preset
mode, and the overall output of channels 13-24 (Preset B) in Double
Preset mode.
To adjust the fade time between the individual steps of a chase.
To adjust the chase speed.
Note: Both the TAP SYNC button and the SPEED fader can be used to set
the chase speed. The last input is valid.
This fader controls the sensitivity of the built-in microphone or of the audio
signal that is fed into the AUDIO input.
Not available.
Used to switch between SINGLE CHASE mode and MIX CHASE mode
when the CHASE/SCENES operating mode is selected.
• SINGLE CHASE: All chase programs will run in sequential order.
• MIX CHASE: All chase programs will run synchronously. In the event
that DMX values contradict each other, the higher value is valid.
Press and hold down this button to hold all adjusted output values. Thus,
it is possible to maintain a current scene.
This button is used to go to next step when the Speed Fader is pushed to
the bottom or in Edit mode.
This button activates sound control mode.
Press and hold down this button to set all control channels to the value
zero regardless of the FULL ON button.
Selects the operating mode: Chase/Scene mode, Double Preset or Single
Preset.
• To switch the flash buttons between the four pages. The LEDs above
the button indicate which page is selected.
• Press this button and the RECORD button to clear the internal memory.
22 • EN
