26 REC EXIT/ADD KILL button
27 RECORD/SHIFT button
28 DOWN/BEAT REV button
29 UP/CHASE REV button
30 DELETE/REV ONE button
31 INSERT/0% OR 0-255 button
32 EDIT/ALL REV button
33 Display with indicators
34 Strobe button
35 Power on/off
36 Power input
37 MIDI THRU/OUT/ IN jacks
38 DMX512 output
39 Polarity switch
40 Line input
41 REMOTE jack
42 FLASH jack
• Press this button and the RECORD button to exit from Program or Edit
mode.
• In Add mode, multiple scenes or flash buttons will be on at a time. Press
this button to select Kill mode. Then pressing any flash button will kill
any other scenes or programs.
• To enable Program mode hold down this button and tap the FLASH
buttons 1, 5, 6 and 8 in sequence.
• Shortly press this button to memorize a step in Program mode.
• Press this button and a flash button (25-24) to memorize a chase
program.
• The Shift function is used in with other buttons.
• The DOWN function allows to modify a scene in Edit mode.
• BEAT REV inverts the running direction of all the programs with
memorized standard speed.
• The UP function allows to modify a scene in Edit mode.
• CHASE REV inverts the direction of all programs currently running.
• DELETE is used to delete a step of a scene.
• REV ONE inverts the running direction of particular program. For this,
press and hold down this button, then press down the FLASH button
corresponding to your desired program and release together.
• INSERT is used to add one or multiple steps to a scene.
• Press this button and the SHIFT button to select the mode of indication
(0% or 0-255) in the display.
• EDIT is used to active Edit mode.
• ALL REV inverts the running direction of all programs.
Shows the current activity or programming state.
Not available.
Switches the controller on and off.
Connect the power adapter provided here.
To interconnect two Scene Setters for data exchange or to connect a
sequencer or another MIDI device.
3-pin XLR jack for connecting the DMX input of the first DMX fixture.
To adjust the polarity of the DMX output.
• left position: PIN 2 = Data -, Pin 3 Data +
• right position: PIN 2 = Data +, Pin 3 Data -
Prior to connecting light effect units, adjust the polarity with the sliding
switch. Set the switch to the left position for EUROLITE devices.
RCA jack for connecting an audio unit with line output (e.g. CD player,
mixer) to control the run of a chase to the rhythm of the music; when
connecting the jack the internal microphone is switched off.
6.3 mm jack for connecting a footswitch.
Not available.
