Dimmer display

1 The display is used to display intensity percentage or absolute DMX value.
2 To change between percentage and absolute value: Press and hold the SHIFT Button. While holding down
the SHIFT button, press the % or 0-255 button to switch between percentage and absolute values.
3 If the display reads, for example, "076", it means a percentage value 76%. If the display reads "076", it means
the DMX value 76.

Blind and Home

1 The Blind function takes channels temporally out from a chase, when the chase is running, and gives you
manual control over the channel.
2 Press and hold the BLIND button and tap the relative FLASH button you want to temporarily take out of the
chase.
3 To return to normal chase again press and hold the HOME Button and push the FLASH Button you want to
return to normal chase.

Add and Kill

1 The ADD/KILL changes the mode of the Flash buttons. As a basic setting, the flash buttons are in Add mode.
Then multiple scenes can be triggered via the Flash buttons.
2 Tapping the ADD/KILL button enables the Kill mode (corresponding LED lights). Then pressing any flash
button will kill any other scenes or programs (they will keep running internally).

Setting MIDI IN

1 Tap the FLASH button 1 three times while holding down the RECORD button. The display reads CHI
indicating MIDI IN channel setup is available.
2 Tap the FLASH button numbered from 1-12 to assign MIDI IN Channel 1-12. The relevant channel LED lights
indicating MIDI IN channel is set.

Setting MIDI OUT

1 Tap the FLASH button 2 three times while holding down the RECORD button. The display reads CHO
indicating MIDI IN channel setup is available.
2 Tap the FLASH button numbered from 1-12 to assign MIDI OUT Channel 1-12. The relevant channel LED
lights indicating MIDI OUT channel is set.

Exit MIDI setting

While holding down the

Receiving MIDI file dump

Tap the FLASH button 3 three time while holding down the RECORD button. The display reads IN indicating the
controller is ready to receive MIDI file dump.

Sending MIDI file dump

Tap the FLASH button 4 three time while holding down the RECORD button. The display reads OUT indicating
the controller is ready to send a file
.
NOTES
1 During file dump, all other operations will not function. Functions will automatically return when the file dump is
completed.
2 File dump will be interrupted and stop if errors occur or power failure.
button tap the
RECORD
.

MIDI SETTINGS

button to exit MIDI setting.
REC EXIT
30 • EN
