6.7 Channel-fader Parameters in the Internal Programs-Mode

PROG SELECT Fader
0-25 R - red
26-51 G – green
52-77 B – blue
78-103 RG – yellow
104-129 RB – violet
130-155 GB – cyan
156-181 RGB - white
182-207 7 Color Program
208-233 Auto Program
234-255 Sound Control

8. CLEANING AND MAINTENANCE

We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no servicable parts inside the device. Maintenance and service operations are only to be carried
out by authorized dealers.
Should you need any spare parts, please use genuine parts.
Should you have further questions, please contact your dealer.

9. TECHNICAL SPECIFICATIONS

Power supply:
Power consumption:
Number of control-channels:
Integrated programs:
Sound-control:
DMX 512-output:
Dimensions (LxWxH):
Weight:
Please note: Every information is subject to change without prior notice. 30.06.2009 ©
SPEED Fader
void
Program Speed
0-255(slow - fast)
void
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
12 V DC, 300 mA, via power unit included in the delivery
3.6 W
5
2
via built-in microphone
3-pin XLR-connector
220 x 140 x 48 mm
1 kg
FLASH/SENSITIVITY Fader
Flash Frequency:
11-255 (slow - fast)
(insensitive – very sensitive)
14/14
0 -10 OFF
Sensitivity:
0 -7 OFF
8 - 255
00041883.DOC, Version 1.1
