The Scene Setter offers three operating modes which can be selected via the MODE SELECT button. The LEDs
below the button indicate which mode is selected.

CHASE/SCENES

1 This mode will give you control of the DMX channels via the upper 12 channel faders. The lower 12 channels
faders will give you access to your memorized chase programs.
2 The master faders are in reverse position, i.e. Master A is at is at its maximum when positioned all the way up,
while Master B is at its maximum when positioned all the way down.

DOUBLE PRESET

1 This mode allows for a special working method often used in smaller theaters. Both fader rows have an
identical function.
2 Both, the upper channel faders 1-12, and the lower channel faders 13-24 control DMX channels 1-12.
3 Master fader A controls channel faders 1-12, and master fader B channel faders 13-24.
4 Example: If both master faders are moved up, they will output the DMX values of the upper channel faders 1-
12. Meanwhile, you can adjust the next scene with the lower channel faders 13-24. If you move both master
faders down, the controller will fade from the upper setting to the lower setting. Then you can prepare the next
scene and fade from the lower setting to the upper setting, etc.
5 This mode cannot be used for programming.

1-24 SINGLE PRESET

This mode will give you control of all 24 DMX channels. Use this mode during a show or in Program mode.

Enable program mode

1 Press and hold down the RECORD button.
2 While holding down the RECORD button, tap the FLASH buttons 1, 5, 6 and 8 in sequence.
3 Release the RECORD button, the RECORD LED lights up, now you can begin programming your chase patterns.
.
NOTE
The first time you turn on your unit, the default setting of the Record Code is Flash buttons 1, 6, 6 and 8. You
may change the Record Code to protect your programs.

Program scenes

1 Enable Program mode.
2 Select the 1-24 SINGLE mode by tapping the MODE SELECT button. This will give you control of all 24
channels as you program. Be sure that MASTER A and B faders are both set to maximum (Master A is at its
maximum when positioned all the way up, while Master B is at its maximum when positioned all the way
down).
3 Create a desired scene using Channel Faders 1-24. At 0% or DMX 255, these faders should be at 10 position.
4 Once the scene is satisfactory, tap the RECORD button to program the scene as a step into the memory.
5 Repeat step 3 and 4 until all desired steps have been programmed into memory.
6 Select a chase bank to store your program. Tap the PAGE button select a page (page 1-4) to store your
scenes.
7 Press a FLASH button between 13-24 while holding down the RECORD button. All LEDs will flash indicating
the scenes have been programmed into memory.
8 If you are not satisfied with the scene or scenes, you may tap the REC CLEAR button while pressing and
holding the RECORD button. All LEDs will flash, indicating the scenes have been cleared.
9 You can continue programming or exit. To exit Program

OPERATING MODES

PROGRAMMING

25 • EN
