POSITION FUNCTION SET Screen (Continued)
Item
BLC Sets of area of back light compensation. Use this function when the object appears
dark (under auto iris control) because of the presence of a bright light source be-
hind it. This function make it possible to place the unnecessary light source outside
the photometry area.
OFF
ARER 1 to AREA 4 : When the SET button is pressed, the fixed light metering ar-
MEMO
When the item "ExDR MODE" (
"---" is displayed. Under this condition, the settings to the item "BLC" cannot be varied.
W. BALANCE Determines the setting of the white balance adjustment. The white balance can be
adjusted for lighting conditions with colour temperatures from 2500K to 8000K.
ATW : Auto-Tracking White balance mode, adjusts the white balance automati-
AWC : Auto White Control mode, which displays "PUSH SET → ADJ. STRAT".
R-B GAIN Adjusts the phases of R (Red) and B (Blue) under AWC mode.
• To enhance blue: Decrease the value.
• To enhance red : Increase the value.
Setting values : 0 to 255
M-G GAIN Adjusts the phases of M (Magenta) and G (Green) under AWC mode.
• To enhance green
• To enhance magenta : Increase the value.
Setting values : 0 to 255

FACTORY SETTINGS screen

This screen resets values to their factory settings.
Item
FACTORY Resets all settings in the above menus to their initial factory settings. Pressing the
SETTINGS SET button displays "EXECUTING" (2 sec. approx.) and resets the settings to the
factory settings.
CANCEL
CLEAR (W/O POS. TITLE) : Resets the settings to the initial, factory settings.
CLEAR (ALL)
Function & Setting
: The backlight compensation function does not work.
eas are displayed.
Select one of the four types.
Pushing the MENU button returns the screen to POSITION
FUNCTION SET.
Photometry area
Photometry area
OFF AREA 1
☞
cally according to the colour temperature of the lighting conditions.
When ATW is set, "---" is displayed for the items "R-B GAIN" and "M-G
GAIN", so that the colour phase adjustment cannot be carried out.
When the SET button is pressed, AWC is activated and the white balance
adjustment starts.
If the AWC is activated while the screen is B&W the LOW LIGHT ERROR
will be displayed. This is not abnormal.
: Decrease the value.
Function & Setting
: Does not alter current values.
However, the set positions, the setting data of each
position and the titles are not reset to the factory set-
tings.
: Resets all settings including titles and stored positions.
Photometry area
Photometry area
AREA 2 AREA 3
page 23) is set to ON, the item "BLC" is set to OFF and
Initial Value
Photometry area
AREA 4
Initial Value
OFF
ATW
95
63
–
E-25
