Jackin g B ar D eta il
Figure 2-3A Jacking Bar Detail
The end of the Jacking Bar rib which is
notched back must be inserted into the slot
first.
G.
Insert the Jacking Bar Retaining Screw into the
slot and, using a screwdriver, tighten the screw
until the Locking Bar is just pressing against the
panel.
5.43 (1 38)
5. 43 (138 )
0.34 (9)
5.4 3 (138)
104 020M A
Siemens AG C79000-G7374-C211-01
SIREC D Manual
T his (N o tched) end
in to s lot firs t.
NOTE
Figure 2-4 Multiple Recorder Cutout Dimensions
H.
Install the other Jacking Bar into the slot on the
opposite side of the Recorder then insert the
Jacking Bar Retaining Screw and tighten as before.
I.
Using the screwdriver, tighten both screws so
that the Recorder is held firmly in place. Torque to
7-9 lb-in.
If the Jacking Bar is in place, back-to-front,
you will be unable to properly tighten it
against the panel.
2.2.4 Multiple Recorder Panel
Mounting.
mounted together in a single panel. Figure 2-4
shows the minimum spacing requirements for
multiple
DM100162 in Chapter 8 of this manual. Install the
Recorders per paragraph 2.2.3, Steps A through I.
0.5 (13)
5.43 (138)
Installation and Wiring
NOTE
Several Recorders
Recorders. Also refer
P anel C utout S ize - 5 .43 (138 ) X 5.43 (138)
Minim um S pacing S ide to S ide - 0.5 (13)
Minim um spacing Top to B ottom - 0.34 (9)
D im ensions are in inches (m illim eters)
