Start-Up
6.1.2

Center DIL switch S2

NOTE
6-4
02.2001
The receive (read) address of the SIMOLINK setpoint telegram is set
on DIL switch S2 (dispatcher mode: Address of setpoint-transmitting
SIMOLINK node).
Switch Designation
0
S2.1 2
1
S2.2 2
2
S2.3 2
3
S2.4 2
4
S2.5 2
5
S2.6 2
6
S2.7 2
7
S2.8 2
Table 6-3 Meaning of DIL switch S2
If the SIMOLINK Encoder is activated even though the receive address
is incorrectly set (i.e. >200), then in the case of hardware version 01 the
wrong receive address is transferred for the read channel and
displayed via LEDs on the housing front panel.
From hardware version 02 onwards, receive addresses from 201...255
(Channel 0 to 7) can also be set on the SLE-DP. But the only values
that make sense are Address 201, Channel 0 (special data double word
1), Address 202, Channel 0 (special data double word 2), Address 203,
Channel 0 (special data double word 3) and Address 204 (special data
double word 4).
SLE / SLE-DP – SIMOLINK Encoder
Meaning
Receive address for setpoint telegram
(part of telegram addressing which
contains the setpoint for the SIMOLINK
Encoder)
Note:
S2.1 is the least significant bit
Receive address for setpoint telegram
for hardware versions from 02 onwards
GWE-477 763 4070.76 J
Operating Instructions
Range
0...200
0...255
