Connections
5-4
02.2001
Setpoint input
Track A
Increasing
setpoints
(pos. rotation)
Track B
Zero track
Track A
Decreasing
setpoints
Track B
(neg. rotation)
Zero track
Table 5-3 Signal output on zero crossover
The number of pulses/rev of the encoder interface can be selected by
means of DIL switches on the right-hand panel (Table 6-1). The
following pulses/rev settings are available: 8192, 4096, 2048, 1024.
SLE / SLE-DP – SIMOLINK Encoder
Signal shape at output
GWE-477 763 4070.76 J
Operating Instructions SIMOVERT MASTERDRIVES
t →
