Operate the roller shutter and allow it to stop
3)
automatically at the upper end limit (if stops) or
lower end limit (if rigid links).
my,
Press for § 2 s, until there is back and
4)
forth movement by the roller shutter.
7KH VHWWLQJ IRU WKH ¿UVW HQG OLPLW LV FRQ¿UPHG
Move the roller shutter to the desired lower end
5)
limit (no rigid links) or upper limit (no stops).
my,
Press for § 2 s, until there are two back
6)
and forth movements by the roller shutter.
The setting for the second end limit is
FRQ¿UPHG
The settings for the end limits are programmed.
The drive enters programming mode for § 10 min. if no control point is programmed.
The procedure for modifying the end limit settings is identical to the initial setting
procedure. To modify the settings at a later time, repeat step 2
Step 3: Programming the Somfy io-homecontrol
If the drive is no longer in programming mode, repeat Step 1 again, before performing
Step 3.
The drive is in programming mode:
%ULHÀ\ press the PROG button on the Somfy
-
®
io-homecontrol
programme:
The roller shutter moves back and forth: the control point has been programmed
in the drive.
Certain control points are equipped with an ON/OFF button. To activate them, press
the ON/OFF button at the rear of the control point.

2.4. TIPS AND ADVICE ON INSTALLATION

2.4.1. Questions on the S&SO-RS100 io?
Observations
The roller shutter does not
operate.
The roller shutter makes
2 brief movements before
H[HFXWLQJ WKH DQG 9
orders and functions at
slow speed.
The rotation direction of
the drive does not self-
adjust automatically.
Copyright © 2014 - 2015 Somfy SAS. All rights reserved.
local control point you want to
Possible causes
The wiring is incorrect.
The overheating protection on
the drive has been activated.
The io-homecontrol ® control
point battery is low.
The control point is not
compatible.
®
The io-homecontrol control
point used is not programmed in
the drive.
The end limit setting in manual
or semi-automatic mode was
interrupted.
This is a small roller shutter of
about 0,5 m² (about 0.6 m x
0.7m).
3) 4)
2
5) 6)
2
b .
®
local control point
PROG. 0.5
Solutions
Check the wiring and modify as required.
Wait for the drive to cool down.
Check the battery and replace it as required.
Contact a Somfy representative.
Use a programmed control point or program this
control point.
If setting in manual or semi-automatic mode is
required: repeat the setting procedure (see Step
a b
2 or Step 2 ). Otherwise move the roller
shutter once to the upper end limit and once to the
lower end limit to return to normal operating mode.
Move the roller shutter to the lower end limit and
raise it, while retaining it slightly with the hand
(without stopping) for 5 seconds. Move it back to
the lower end limit. The next move, the drive has
found its rotation direction.
Non contractual images.
