KEB COMBIVERT G6 Gebrauchsanleitung Seite 46

FUNKTIONALE SICHErHEIT
• In order to comply with CSA C22.2 No. 14-2010 (cUL) following external Input
Table 1: Mains input chokes for CSA applications:
Cat. No. Housing Input Voltage [V]
10G6
12G6
13G6
Branch Circuit Protection for G6 - B Drive series
I) Fuses:
The voltage rating of the external fuses shall be at least equal to the input voltage of the
drives.
46
Chokes need to be installed: See table 1 below!
B 480 / 3ph
B 480 / 3ph
B 480 / 3ph
Cat. No. Housing
10G6 B
12G6 B
13G6 B
Reactor Cat. No.
10DRB08-3751
12DRB08-2851
13DRB08–1851
Input Voltage
[V] UL248 Fuse rating 600V [A]
480 / 3ph
480 / 3ph
480 / 3ph
FLA Inductance [mH]
3 x 8A 3.66
3 x 10A 2.93
3 x 16A 1.83
Class CC, J or RK5
10
15
20
