Information fields, which you cannot change, appear
first:
– Device Type
– Bluetooth Address
– Serial Number
Three editing fields follow, in which you can enter
your own data:
– User Name with at most 19 characters,
– User ID with at most 19 characters,
– User Information with at most 39 characters.
Screwdriver Settings
Left rotation allowed:
The default setting is On.
You can switch between On and Off.
Communication and theft protection:
The default setting is On.
Note: You should retain this setting so that data
transmission is possible.
When you click Off, data is no longer transmitted.
Data could thus be lost.
Theft protection delay [5 s increments]:
In the default setting, the value is set at 60 s.
Here, enter the time in seconds after which a
screwdriver that is not located in the transmitting
range of the access point is to be locked automat-
ically (minimum value, 5 s; maximum value, 60 s).
The entry in this field is taken into consideration
only when in the setting Theft protection On is ac-
tivated.
Double hit detection time [50 ms increments]:
In the default setting, this value is set at 100 ms.
Here, enter a time, in increments of 50 ms (maxi-
mum value, 1000 ms), within which the attempt to
tighten a screw once again is to be regarded as a
double hit error.
Repeat protection [100 ms increments]:
In the default setting, the value is set at 700 ms.
Here, enter a time period, in increments of
100 ms (minimum value, 300 ms; maximum val-
ue, 1000 ms), within which a repeat protection is
to be activated. It is not possible to switch the
screwdriver back on prior to the expiration of this
time.
Job Settings
Number of fasteners per job:
The default setting is the value: 5.
Here, enter how many screw fasteners are to be-
long to a screwing job (minimum value, 1; maxi-
mum value, 255).
Job release:
The default setting is Manually.
The screwing job is released here through the
software by mouse click.
You many choose, via a dropdown menu, how
the screwing job is to be released (e.g., through
input signals of a release button or of a PLC).
3 609 929 A58 • (05.09) T
Lock after number of fasteners NOK:
The default setting is the value: 0. The function is
out of operation.
Here, enter how many flawed screw fasteners you
permit a screwing job before the screwdriver is
locked and the screwing job is terminated with a
corresponding error code (maximum value, 255).
The locking generates a warning, which you must
confirm with OK. Subsequently, you can contin-
ue to work with the selected settings.
Count Strategy:
The default setting is Plus 1 if OK
Only correct screw fasteners are counted.
Via a dropdown menu, you can additionally se-
lect:
Do not count fasteners
No screwing job is assigned.
Plus 1 if OK or NOK
All screw fasteners are counted.
Reset to 0 if NOK
When a screwdriving action is flawed, the entire
screwing job is repeated.
Min. fastener time [50 ms increments]
The default setting is the value: 0. The function is
out of operation.
Here, enter the time, in increments of 50 ms, for
the individual screw fasteners (minimum value,
50 ms; maximum value 10,000 ms).
Max. fastener time [50 ms increments]
The default setting is the value: 0. The function is
out of operation.
Here, enter the time, in increments of 50 ms, for
the individual screw fasteners (minimum value,
50 ms; maximum value 10,000 ms).
Enter plausible values, because, otherwise, there
appears an error message, which you must con-
firm with OK. The program does not correct the
incorrect entry.
If the required fastener time lies outside of the
plausible timeframe, the screw fastening is termi-
nated with a corresponding error code and the er-
ror code is shown in the screw fastener table of
the EXAConnecT and Screwdriver Register
Cards.
Min. job time [250 ms increments]
The default setting is the value: 0. The function is
out of operation.
Here, enter the time, in increments of 250 ms, for
the entire screwing job (minimum value, 250 ms;
maximum value, 600,000 ms).
The program checks whether the entered value is
divisible by 250 and is larger than the value for the
Min. fastener time. Otherwise, there appears an
error message, which you must confirm with OK.
Please check the values once again for correct-
ness after saving – clicking of OK or Apply.
