Important notice: Some of the following symbols could have meaning for the use of your tool. Please take
note of the symbols and their meaning. The correct interpretation of the symbols will help you to use the tool
in a better and safer manner.
Symbol Name
V Volt
A; mA Ampere; Milliampere
W; Hp Watt; Horsepower
Hz Hertz
kg; lbs Kilograms; Pounds
mm; in Millimeter; Inches
DD; MM; YYYY Day; Month; Year
HH; MM (min); Hours; minutes;
SS (s); ms Seconds; Milliseconds
°C Degrees Celsius;
°F Degrees Fahrenheit
Direct current
Single-phase alternating current
Protection class I
(Earthing terminal)
IP 54 Type of protection provided by the
housing according to IEC 60529
Dangerous electrical voltage
Warning symbol
Symbol for directions
3 609 929 A58 • (05.09) T
SYMBOLS
Meaning
Voltage
Current
Power
Frequency (cycles per second)
Mass, weight
Length
Time, Duration
Temperature
Type or a characteristic of current
Type or a characteristic of current
Grounding terminal
Equipment with protection class IP 54 is protect-
ed against dust and splash water
Only technically competent persons may open
the operating area thus marked.
Alerts user to warning messages
Gives instructions for correct handling – for exam-
ple, use tool only in enclosed work sites, read op-
erating instructions, and do not dispose of tool in
household waste
English–2
