6 Initial commissioning
and setting up
Always consider the following when put-
ting into operation and setting up smoke
alarm devices:
f Commission devices in a radio
group one after another in their final
installation location.
f To prevent overlaying radio signals,
keep a minimum distance of 2 to
3 m between the devices.
f Establish a radio group of at least 2
and a maximum of 15 smoke alarm
devices connected together.
f Connect a maximum of 15 radio
groups together.
f After putting the device into operati-
on, the splint pin is used as a tool
for operating the radio button, and
must be kept readily available in the
vicinity of the device.
60
Operating Manual: PX-1C - Smoke Alarm Device with Radio Link
Shared radio group and subgroup
For special applications, it may be useful
to set up a shared radio group e.g., in
the corridor of an apartment building. A
central radio group (corridor) which is
associated with one or more other radio
groups (flat) thereby takes over the func-
tion of the shared radio group. The other
radio groups form subgroups.
Alarm signals are passed only to the
shared radio group from an alarming sub-
group and trigger it. Alarm forwarding
from the shared radio group to the sub-
group does not occur.
f Set up all the individual groups one
after another before connecting the
individual radio groups.
