3.2 Controls
Fig. 10 Controls
1 Splint pin (activation backup)
2 Activation button
3 Magnet carrier
4 Signal LED
48
Operating Manual: PX-1C - Smoke Alarm Device with Radio Link
5 Radio button
6 Smoke intake lamellas
7 Testing/stop button
(smoke alarm device cover)
