Splint pin (activation backup)
The splint pin (activation backup) is used
during the transport of the device to pro-
tect against accidental activation.
After commissioning the device, the splint
pin (activation backup) is used as a tool
for operating the radio button, and must
be kept readily available in the vicinity of
the device.
Activation button
The activation button is used to turn the
device on and off.
Magnet carrier
The magnet carrier is used for fastening
the device.
Signal LED
The signal LED displays results and inter-
mediate results during start-up of devices
and setting up of radio groups or shared
radio groups.
EN
EN
Operating Manual: PX-1C - Smoke Alarm Device with Radio Link
Radio button
The radio button is found in the opening
marked with an arrow. It is used to set up
the radio connection between devices.
Smoke intake lamellas
Smoke from the fire reaches the inside
of the device through the smoke intake
lamellas and can then be detected by
sensors.
Testing/stop button
(smoke alarm device cover)
The testing/stop button (smoke alarm
device cover) is used for a self-test, for
correct wireless connection between
multiple devices or between devices of
a radio group.
The testing/stop button (smoke alarm de-
vice cover) can be actuated to interrupt
or stop alarm and alert tones.
