5 Installation

The device is held by a magnet carrier at
the installation location. The magnet car-
rier can be mounted by gluing or drilling.
To avoid injuries from improper
installation, the instructions in this manual
must be followed. The general safety reg-
ulations should also be observed.
CAUTION
Possible property damage!
Using other fastening material (not
enclosed) or wrong conditions at the
installation location can cause the
device to fall down.
f Use only the supplied mounting
material (adhesive pad or screws/
dowels).
f Ensure that the installation
location is strong enough, solid,
dry, free from grease, dust and
loose paint etc.
f Note that the magnet carrier
magnetically attracts only from
one side.
56
Operating Manual: PX-1C - Smoke Alarm Device with Radio Link

5.1 Adhesive mounting

The magnet carrier can be mounted using
adhesive assembly as follows:
Easy to maintain and removable ac-
•
cording to EN 14604:2005/AC:2008 or
maintenance-unfriendly but theft-
•
proof according to
EN 14604:2005/AC:2008
and vfdb 14/01 (Q)
Adhesive mounting according to
EN 14604:2005/AC:2008
When performing this type of installation,
proceed as follows:
(1) Remove magnet carrier from the
device. (Remove the splint from the
activation button only after that.)
f To do this, tilt the magnet carrier.
(2) Remove the protective film from the
adhesive pad on the magnet carrier.
