Graco ProMix PD2K Bedienungsanleitung Seite 5

Figure 3 Typenschild des Modells AC2000
(Hochdruck)
Figure 4 Typenschild des Modells AC0500
Figure 5 Typenschild des nicht eigensicheren Farbwechselreglers (Zubehör)
Figure 6 Typenschild des eigensicheren
Farbwechselreglers (Zubehör)
3A5226F
®
ProMix PD2K / PD1K
Electronic Proportioner
II 2 G
FM16US0241
Ex ia IIA T3
FM13 ATEX 0026
FM16CA0129
IECEx FMG 13.0011
Intrinsically safe
equipment for Class I,
Div 1, Group D, T3
Ta = 2°C to 50°C
MAX AIR WPR
.7 7 100
MPa bar PSI
MAX FLUID WPR
10.34 103.4 1500
MPa bar PSI
MAX TEMP 50°C (122°F)
®
ProMix PD2K / PD1K
PART NO. SERIES
Intrinsically safe equipment
for Class I, Div 1, Group D, T3
Ta = 2°C to 50°C
Install per 16P577
FM16US0241 FM16CA0129
Artwork No. 294055 Rev. C
Intrinsically Safe (IS) System. Install
per IS Control Drawing No. 16P577.
Control Box IS Associated
Apparatus for use in non hazardous
location, with IS Connection to color
change and booth control modules
Apparatus for use in:
Class I, Division 1, Group D T3
Hazardous Locations
Read Instruction Manual
Warning: Substitution of components
may impair intrinsic safety.
PART NO. SERIES
MFG. YR.
COLOR CHANGE CONTROL
SERIAL MFG. YR.
.7
MPa
II 2 G
Ex ia IIA T3 Gb
FM13 ATEX 0026
IECEx FMG 13.0011
SERIAL
GRACO INC.
P.O. Box 1441
Minneapolis, MN
55440 U.S.A.
MAX AIR WPR
7 100
bar PSI
GRACO INC.
P.O. Box 1441
Minneapolis, MN
55440 U.S.A.
Modelle
5
