The Ubiflux F150 - F200 - F300 can directly be mounted to the wall
GB
or ceiling using the mounting brackets supplied for that purpose.
Because of the appliance's weight, mounting the ap-
pliance must always be done by two people!
The Ubiflux F can directly be mounted to the wall/ ceiling using the
suspension brackets supplied for that purpose. For a vibration-free
result the appliance must be mounted to a solid wall with a mini-
mum mass of 200 kg/m
not suffice! Additional measures such as double panelling or extra
studs are required in that case. In addition, the following aspects
must be taken into account.
• The appliance must be placed level; both lengthwise and late-
rally.
• The installation room must be such that a good condensate
discharge with air trap and pitch for condensate can be made
We recommend not to install the heat recovery unit in
•
spaces with an average high RH (for instance bathroom).
That will prevent condensation on the outside of the heat
recovery unit.
Make sure that under no condition the condensate
discharge is installed at a pitch towards the appli-
ance!
The appliance is only suitable for ceiling or wall
mounting! Never mount the appliance flat on the
floor because of the position of the condensate di-
scharge bin!
36
. A gypsum block or metal stud wall does
2
Ubiflux F150(+) - F200(+) - F300(+)
Installeren/ Installion/ Installation/
• The installation room must be isolated.
• When mounting lexible ducts, bear in mind that it must be
possible to replace them in due course.
• Make sure there is sufficient free space at the appliance to
allow cleaning of the filters and maintaining the appliance. It
must be possible to swing the door open.
• Avoid the use of petroleum-based adhesives in air plan systems.
• Dwellings with construction moisture must be ventilated
naturally during a certain period!
Ceiling mounting:
At least 70 cm at the underside of the appliance and a free
headroom of 1.8 m; if 70 cm free space is not available, for
instance when mounting on top of a suspended ceiling, there
. must be sufficient room to partly open and remove the front
panel.
The front panel can be detached after removing a lock
screw at the hinge! (
Make sure the filters can always freely be removed, so there
is no frame or other obstacle at the level of the filters!
Wall mounting :
Make sure there is a free space of at least 70 cm at the front
of the appliance and a free headroom of 1.8 m.
• Make sure there is at least 10 cm free space at the appliance
side where the electric connections are located, so connec-
tors and sleeves remain accessible.
