STEP NO. DESCRIPTION
Extract fan mode
19
switching input 1
20 Selection input 2
21 Minimum voltage input 2
22 Maximum voltage input 2
Conditions
23
switching input 2
Supply fan mode
24
switching input 2
Extract fan mode
25
switching input 2
26 Geo heat exchanger
Minimum temperature
geo heat exchanger
27
(Below this temperature
the valve opens.)
Maximum temperature
geo heat exchanger
28
(Above this temperature
the valve opens.)
136
Instelwaarden/ Setting values/ Einstellwerte
FACTORY SETTINGS
UBIFLUX F300+
5
ON
0,0 V
10,0 V
0
5
5
UIT
5,0 °C
25,0 °C
Ubiflux F150(+) - F200(+) - F300(+)
Valeurs de réglage
ADJUSTING RANGE
0 (= Extract fan off)
1 (= Absolute min. flow rate 50m
2 (= Flow rate mode 1)
3 (= Flow rate mode 2)
4 (= Flow rate mode 3)
5 (= Multiple switch)
6 (= Maximum flow rate)
OFF ( = Switching input 2 active)
ON (= 0 - 10 volt input 2 active)
0,0 Volt - 10,0 Volt
0,0 Volt- 10,0 Volt
0 (off)
1 (on)
2 (= On if conditions
bypass open satisfied)
3 (= Bypass control)
4 (= Bedroom valve)
0 (= Input fan off)
1 (= Absolute min. flow rate 50m
2 (= Flow rate mode 1)
3 (= Flow rate mode 2)
4 (= Flow rate mode 3)
5 (= Multiple switch)
6 (= Maximum flow rate)
0 (= Extract fan off)
1 (= Absolute min. flow rate 50m
2 (= Flow rate mode 1)
3 (= Flow rate mode 2)
4 (= Flow rate mode 3)
5 (= Multiple switch)
6 (= Maximum flow rate)
OFF (= Valve control geo heat
exchanger off)
ON (= Valve control geo heat
exchanger on)
0,0 °C - 10,0 °C
15,0 °C - 40,0 °C
STEP
/h)
3
0,5 V
0,5 V
/h)
3
/h)
3
0,5 °C
0,5 °C
