URUCHAMIANIE SILNIKA IL. 6-10
Rozruch na zimno
1
Otworzyć zawór paliwowy (4) w lewo (il. 6)
2
Otworzyć zawór paliwowy (21) na silniku (rys. 6.1),
przekręcając go w prawo do ustawienia „ON".
3
Dźwignię zasysacza (8) ustawić w pozycji „ZA-
MKNIĘTY". (il. 6.2)
4
Dźwignię gazu (11) przesunąć lekko w lewo. (il. 7)
5
Włącznik zapłonu (9) ustawić w pozycji „ON / EIN"
(il. 8).
6
Lekko pociągnąć rozrusznik linkowy (10), aż będzie
wyczuwalny opór, a następnie pozwolić na ponowne
nawinięcie. (il. 9)
7
Energicznie, unikając szarpania pociągnąć rozrusz-
nik linkowy (10). Następuje rozruch silnika.
8
Ustawić dźwignię regulacji gazu (11) w pozycji biegu
jałowego.
9
Otworzyć zasysacz (8) podczas rozgrzewania sil-
nika.
10 Powoli i ostrożnie przesuwać w lewo dźwignię regu-
lacji gazu (11) – maszyna zaczyna pracować.
Rozruch na ciepło
1
Otworzyć zawór paliwowy (4) w lewo.
2
Otworzyć zawór paliwowy (21) na silniku (rys. 6.1),
przekręcając go w prawo do ustawienia „ON".
3
Dźwignię zasysacza (8) ustawić w prawo w pozycji
„OTWARTY".
4
Ustawić dźwignię regulacji gazu (11) w pozycji biegu
jałowego.
5
Włącznik zapłonu (9) ustawić w pozycji „ON / EIN".
6
Lekko pociągnąć rozrusznik linkowy (10), aż będzie
wyczuwalny opór, a następnie pozwolić na ponowne
nawinięcie.
7
Energicznie, unikając szarpania pociągnąć rozrusz-
nik linkowy (10). Następuje rozruch silnika.
8
Powoli i ostrożnie przesuwać w lewo dźwignię regu-
lacji gazu (11) – maszyna zaczyna pracować.
UWAGA!
Beim Motor-Starten, den Choke immer nur öffnen, wenn
der Gashebel im Leerlauf steht, ansonsten kann sich
der Stampfer in Bewegung setzen.
Den Vibrationsstampfer aus der Ruhestellung langsam
in Vollgasstellung hochfahren.
Wyłączanie silnika
1
Dźwignię regulacji gazu (11) przesunąć w prawo do
pozycji biegu jałowego.
2
Włącznik zapłonu (9) ustawić w pozycji „OFF / AUS".
3
Zawór paliwa (4) w prawo
4
Zamknąć zawór paliwowy (21), przekręcając go w
lewo.
5
Wskazówka! Gwałtowne wyłączenie silnika przy
pełnych obrotach może doprowadzić do uszkodze-
nia silnika.
STARTING THE MOTOR FIGS. 6-10
Cold start
1
Set the fuel cock (4) to the left. (Fig. 6)
2
Turn the fuel valve (21) on the motor (Fig. 6.1) to the
right, to the "ON" position, to open it.
3
Set the choke lever (8) to the left to "CLOSED". (Fig.
6.2)
4
Move the gas lever (11) somewhat to the left. (Fig. 7)
5
Set the starter switch (9) to "ON/EIN". (Fig. 8)
6
Lightly pull the choke (10) until you encounter resist-
ance and let it roll back in. (Fig. 9)
7
Pull the starter cable (10) out hard, but not jerkily.
The motor starts.
8
Set the gas lever (11) to idle.
9
Open the choke (8) while the motor warms up.
10 To begin use, move the gas lever (11) to the left
slowly and carefully - the machine begins to work.
Warmstart
1
Set the fuel cock (4) to the left.
2
Turn the fuel valve (21) on the motor (Fig. 6.1) to the
right, to the "ON" position, to open it.
3
Set the choke lever (8) to the right to "Open".
4
Set the gas lever (11) to idle.
5
Set the starter switch (9) to "ON/EIN".
6
Lightly pull the choke (10) until you encounter resist-
ance and let it roll back in.
7
Pull the starter cable (10) out hard, but not jerkily.
The motor starts.
8
To begin use, move the gas lever (11) to the left
slowly and carefully - the machine begins to work.
CAUTION!
When starting the motor, always open the choke only
when the gas lever is set to idle; otherwise, the Rammer
can start moving.
Slowly accelerate the vibration Rammer from the rest
setting to the full throttle setting.
Turn off the motor
1
Move the gas lever (11) to the right into the idle po-
sition.
2
Set the starter switch (9) to "OFF/AUS".
3
Move the fuel cock (4) upward to close it.
4
To close the fuel valve (21), turn it to the left. Note!
Suddenly turning off the motor at full throttle can
damage the motor.
31
