Trimming panel
Fig."A3"
Fit the trimming panels and screw them to the frame feet
with
4 flat round self-tapping screws
for each panel.
Fit the plastic foot plates, tapping lightly with the ham-
mer.
Frame feet
Fig."B"
Mount the frame feet with
4 flat round collar screws M 8 x 25 for each foot
4 serrated edge washers 8.2 for each foot
4 hexagon nuts M 8 for each foot
Mounting of traversing gear (special accessories)
Saw blade - splitting wedge
Fig."C+D"
To fit the saw blade, remove the bench insert from the bench
top as folIows.
Fig. ,,D"
1 fixing pin
2 saw blade
3 clamping ftange
4 nexagon nut M 20 Ieft
5 splitting wedge
6 clamping plate
7 nexagon nut M 12
• Turnn the motor. right to the top with the handwheel
• Insert the fixing pin (1) through he
front panel into the saw blade shaft,
pushing it with an upward slant.
• Countert he saw shaft with the fixing
pinto loosen or tighten the hexagon nut M20.
Secure the saw blade (2) with the
clamping washer (3) and hexagon nut M 20 (4).
• Fit the splitting wedge (5) and tighten
with the clamping plate (6), hexagon nut (7) and
washer
Fig. „D1"
The gap between the saw blade ill and
the splitting wedge must not be more than 8 mm.
Check and read just it if necessary after each saw blade
change. The lip 01 the splitting wedge must never be set
Iower than the fIoot 01 the top saw tooth.
A setting 01 max. 2 mm below the crest of tne top saw
tooth is ideal.
The splitting wedge is an important
salety leature.
The work.piece is fed through the splitting
wedge, which prevents the cut from closing behind the
saw blade and also prevents the workpiece from kicking
back.
The splitting wedge mus! be flush in line with the saw blade.
Make a fine adjustment if necessary. Fine adjustment is
4.8 x 9.5 made using hexagon nuts M 8 -size 13 (2) at the top and
bottom 01 the guide bar (1).
Close the cover of thee protective casing and replace the
bench insert.
Cowl
Ag. „E"
Mount the cowl.
1 fial round screw
1 springwasher
1 wingnul
Impartant:
Longitudinal fence
Fig."F"
Bolt together the stop tube, intermediate plate and guide
slide. To do this, insert the two threaded bolts into the
guide slide.
4 washer
4 cheese-head screws
Fig."G"
Bolt the intermediate plate onto the stop tube.
Do not tighten
2 cheese-head screws
2 washers
2 wingnuts
Fig."H"
Bolt the two supports to the underside of the bench top.
2 cheese-head screws
2 washers
Tighten the cheese-head screws hand-tight only tor the time
being.
The cowl musl lie horizontatly
ill abovethesplitting wedge during
all working procedures!
M6 x35
A 6
M6
M6 x 40
M6 x 75
6
M6
M 8 x 20 each
ø 8 each
