• Circular saw blades made of super­high­speed steel
must not be used.
• Safety devices on the machine must not be dismantled
or put out of action.
• The splitting wedge is an important safety feature.
The workpiece is fed through the splitting wedge,
which prevents the cut from closing behind the
saw blade and also prevents the workpiece from
kicking back.
• Always lower the protective cover over the workpiece
for each operation.
• The cowl must stand horizontally above the saw
blade during all working procedures.
• Always use the push­stick for longitudinal cutting
of narrow workpieces of less than 120 mm.
• Always stop the machine and disconnect the
mains plug before remedying faults or removing
jammed pieces of wood.
• Replace the blade­slot insert if it is damaged.
Disconnect the mains plug!
• Always switch off the motor, and disconnect the
mains plug before completing and conversions,
adjustments, measurements and cleaning work.
• Use the scheppach Exhaust System woova 3.0 or
woova 5.0 for the exhaust removal of saw dust.
The flow velocity in the suction nozzle must be
16 meters/sec.
• When leaving the work place, switch the motor
off. Pull the power supply plug.
• Cut off the external power supply of the machine
or plant even if inly minor changes of place are
envisaged. Properly reconnect the machine to the
supply mains before recommissioning.
• Connection and repair work on the electrical
installation may be carried out by a qualified
electrician only.
• All protection and safety devices must be
replaced after completing repair and maintenance
procedures .

Use only as authorized

The machine meets valid EC machine guidelines.
• The machine must only be used in technically
perfect condition in accordance with its designated
use and the instructions set out in the operating
manual, and only by safety-conscious
persons who are fully aware of the risks involved
in operating the machine. Any functional disorders,
especially those affecting the safety of the
machine, sholud terefore be rectified immediately.
• The scheppach Table Circular Saw is constructed
exclusively for working with wood and non­ferrous
materials.
• When used in enclosed rooms, the machine must
be connected to a vacuum exhaust unit.
Use the scheppach dust extractor woova 3.0 or
woova 5.0 to remove matchwood or saw dust. The
vacuum support flow rate must be 20 mls.
Subatmospheric pressure 1200 Pa.
• The scheppach automatic switching unit is available
as a special accessory.
Type ALV 2 Art.No 79104010 230V/50 Hz
TypeALV10 Art.No 79104020 400V/230 V/50 Hz
The vacuum exhaust unit automatically switched
on after a 2-3 second delay after the machine tool
is turned on. This avoids overloading the circuit fuse.
After turning off the machine tool, the vacuum
exhaust unit remains on for an additional 2­3
seconds and is then automatically switched off.
Remaining dust is thereby removed by vacuum
exhaust, as required by German regulations
governing hazardous materials. This results in
savings in electricity consumption and reduces
noise levels, as the vacuum exhaust unit is on only
during machine tool operation.
• For work in commercial spaces, the scheppach
dust extractor must be used. Do not remove or
shut of vacuum exhaust unit systems or dust removers
while machine tool operating.
• The scheppach circular saw bench has been
designed to be used exclusively with scheppach
tools and accessories for sawing wood. Be sure to
securely hold and feed all work pieces when sawing.
• Any other use exceeds authorization. The manufacturer
is not responsible for any damages
resulting from unauthorized use; risk is the sole
responsibility of the operator.
• The safety, work and maintenance instructions of
the manufacturer as weil as the technical data
given in the calibrations and dimensions must be
adhered to.
• Relevant accident prevention regulations and
other, generally recognized safety-technical rules
must also be adhered to.
• The scheppach Table Circular Saw may only be
used, maintained, and operated by persons
familiar with and instructed in its operating and
procedures. Arbitrary alterations to the machine
release the manufacturer from all responsibiliy for
any resulting damages. .
• The scheppach Table Circular Saw may only be
operated with original accessories and original
add-on devices and saw blades from the manufacturer.

Remaining hazards

The machine has been built using modern technology
in accordance with recognized safety rules.
Some remaining hazards, however, may still exist.
• The rotating saw blade can cause injuries to
fingers and hands if the work piece is incorrectly fed.
• Thrown work pieces can lead to injury if the work
piece is not properly secured or fed, such as
working without a limit stop.
• Wood chips and sawdust can be health hazards.
Be sure to wear personal protective gear such as
safety goggles and a dust mask. Use a vacuum
exhaust system.
• Noise can be a health hazard. The permitted noise
level is exceeded when working. Be sure to wear
personal protective gear such as ear protection.
• Defective saw blades can cause injuries. Regularly
inspect the structural integrity of saw blades.
• The use of incorrect or damaged mains cables
can lead to injuries caused by electricity.
• Even when all safety measures are taken, some
remaining hazards which are not yet evident may
still be present.
• Remaining hazards can be minimized by following
the instructions in „Safety Precautions", „Proper
Use" and in the entire operating manual.
english 13
