1 Cap
2 O-ring
3 Screw CSK M8 x 16
4 Retaining Washer
Clutch Nut (LP)
5
Clutch Nut (Capstan)
6 Washer - Castan only
7 Capstan
8 Clutch Cone
9 Bellville Washer
10 Cap screw -M5 x 16
Chainwheel 10mm - 3/8" CW
Chainwheel 10mm - 3/8" ACW
Chainwheel 11mm - 3/8" CW
11
Chainwheel 11mm - 3/8" ACW
Chainwheel 12mm/13mm -1/2" CW
Chainwheel 12mm/13mm -1/2" ACW
12 Bush
13 Cap screw -M6 x 70
14 Spring washer
15 Stripper
17 Retaining Clip
18 Seal
19 Bearing
Part
Qty Kit
no
1 7191
P104750
1 SP2790
1 SP0064
1 3267
1 7440
1 7441
1 7527
1 7443
2 7439
2 5015
3 SP0178
1 P103317
1 P103321
Pre-Assembled
Kit includes
1 P103325
items 10,11,
1 P103326
12 & 17
ref see 7.7
1 P103318
1 P103322
1 7544
2 SP4509
2 SP0474
1 7444
2 2311
1 SP2799
1 SP0657
User's Manual • Benutzerhandbuch • Manuel d'Utilisation du Treuil • Manual del Usuario • Gebruikershandleiding • Manuale Utente
7.5 Windlass Parts - Topworks • Bestandteile der Ankerwinde - Kopfstücke • Pièces du guideau – Mécanismes inférieurs
Piezas del molinete - Trabajos en la parte superior • Ankerlieronderdelen - Bovendeks • Parti del mulinello - strutture superiori
Item
Component Description
no
Spring CW
20
Spring ACW
21 Pressure Arm
Deckplate CW
22
Deckplate ACW
23 Deck Gasket
Stud - 90TDC
24
Stud - 190TDC
25 Washer
26 Spring Washer
27 Nut - M10
28 Spring
29 Pawl
30 Washer
31 Cap screw -M8 x 25
32 Plug
33 Bush
34 Screw -M10 x 35
35 Pawl
36 Bush
37 O-ring
38 Cap screw -M6 x 16
39 Key
40 Key - Capstan
CW - clockwise
ACW - anticlockwise
Part
Qty Kit
no
1 7037
P104752
includes items
1 7436
13,14, 20 & 21
ref see 7.7
1 7435
1 7430
1 7431
1 7515
5 5225
5 7482
5 3843
9 SP0466
5 SP0371
1 7458
1 7456
1 SP0413
1 SP0158
1 SP3519
1 SP3518
4 SP3221
1 7457
1 7480
1 SP2785
1 SP0170
2 7465
1 3150
