Scheppach HP1900S Originalbetriebsanleitung Seite 26

Table of contents
1 Introduction ........................................................
2 Proper use..........................................................
3 Product description (Fig. 1-20)...........................
4 Scope of delivery (Fig. 2) ...................................
5 Unpacking ..........................................................
6 Technical data....................................................
7 Safety instructions..............................................
8 Assembly............................................................
9 Before commissioning........................................
10 Operation ...........................................................
11 Working instructions (Fig. 1) ..............................
12 Cleaning and maintenance ................................
13 Storage and transport ........................................
14 Repair and ordering spare parts ........................
15 Disposal and recycling .......................................
16 Troubleshooting .................................................
17 EU Declaration of Conformity.............................
18 Exploded view .................................................... 124
Explanation of the symbols on the
product
Symbols are used in this manual to draw your attention to
potential hazards. The safety symbols and the accompa-
nying explanations must be fully understood. The warn-
ings themselves will not rectify a hazard and cannot re-
place proper accident prevention measures.
Attention! Failure to observe the safety signs
and warning information affixed to the prod-
uct and failure to observe the safety and op-
erating manual can result in serious injury or
even death.
Before commissioning, read and observe
the operating manual and safety instruc-
tions!
Before commissioning, read and observe
the operating manual and safety instruc-
tions!
Wear hearing protection.
Wear safety goggles.
Wear safety gloves!
Wear sturdy footwear!
26 | GB
27
27
27
28
28
28
29
31
31
33
34
34
37
38
39
39
40
106
www.scheppach.com
Removing or modifying protective or safety
equipment is prohibited.
Do not touch rotating parts. Getting caught
in the spinning belt will cause a hand injury.
Always put on the belt guard.
Naked flames or smoking near the device is
strictly prohibited!
Warning - Hot surfaces!
Attention: hot surface - danger of burning.
Clean the air filter in accordance with the in-
structions.
Keep third parties away from the work area.
Danger of poisoning! Only use the product
outdoors and never in closed or poorly venti-
lated rooms.
Important. The exhaust gases are toxic. Do
not operate the engine in areas that are not
ventilated.
Important. Always switch off the engine be-
fore refuelling. Do not refill during operation.
Before carrying out any cleaning or mainte-
nance work, switch off the engine and re-
move the spark plug connector from the
spark plug.
- Choke closed
- Fuel valve open
Speed lever
Checking the oil level
The eccentric vibration unit is already filled
with oil! Do not top up. Oil level not visible.
Guaranteed sound power level of the prod-
uct.
