To Avoid Further Blockage; Trouble Shooting Guide - Gastroback DESIGN MULTI JUICER Bedienungsanleitung

3. Remove residue of food on the filter basket with a small wooden or plastic spoon.
4. Assemble the appliance according to the instructions and continue juicing.
5. If another blockage occurs clean the appliance according to the instruction ›Care and
Cleaning‹.
To avoid further blockage:
• When juicing hard or stringily fruit or vegetables choose a high speed.
• Remove very hard and stringily elements such as stalks and stems.
• Try slower juicing action by pushing the food pusher down more slowly.
• Avoid overloading pulp in the pulp container. The pulp has to be able to fall easily and
unhindered into the pulp container.
• Try other fruit and vegetables.

TROUBLE ShOOTING GUIDE

Possible problem
Machine will not work when
switched on
Motor appears to stall when juicing Wet pulp can build up under the juicer cover if the
Excess pulp building up in the stain-
less steel filter basket
Pulp too wet and reduced
extracted juice
Easy solution
The safety locking arm may not be correctly
engaged in the vertical operating position with
the locking arm located into the two grooves on
either side of the juicer cover (see ›Assembling the
appliance‹).
juicing action is too vigorous. Try slower juicing
action by pushing the food pusher down more
slowly. Follow ›Disassembling the appliance‹ and
›Care and cleaning‹ instructions and clean the filter
bowl surround, the stainless steel filter basket and
the juicer cover.
Stop the juicing process and follow Disassembling
instructions. Remove the juicer cover, scrape off
pulp, reassemble and begin juicing again. Try
alternating (soft and hard) vegetables and fruit
varieties.
Try a slower juicing action. Remove stainless steel
filter basket and thoroughly clean mesh walls with a
cleaning brush. Rinse the stainless steel filter basket
under hot water. If the fine mesh holes are blocked,
soak the basket in a solution of hot water with 10%
lemon juice to unblock the holes or wash in the
dishwasher. This will remove excess fibre build up
(from fruit or vegetables) which could be inhibiting
the juice flow.
