Emptying The Pulp Container During Juicing; Overheat Protection; Disassembling Your Juicer - Gastroback DESIGN MULTI JUICER Bedienungsanleitung

Fruits / Vegetables
Oranges (peeled)
Peaches (stone removed)
Pears (stalks removed)
Pineapple (peeled)
Plums (stone removed)
Raspberries
Tomatoes
Watermelon (peeled)
Empty the pulp container during juicing
The pulp container can be emptied during juicing by turning the appliance ›OFF‹ at the
control panel and then carefully removing the pulp container. Remove the pulp container
by tilting the pulp container slightly to the right and unlatch it from under the juicer cover
and the container support extending from under the motor base. Replace the empty pulp
container into position before continuing to juice.
overheat protection
The »Design Multi Juicer« will automatically stop operating if the motor is stalled for more
than 10 seconds. This is a safety feature. Either too much food is being processed at one
time or the pieces are not small enough. Try trimming food, cutting food into smaller pieces
of even size and/or processing a smaller amount per batch. To continue juicing, reset the
appliance by pressing the ›ON/OFF‹ switch on the control panel to ›OFF‹, then turn the
appliance back on by pressing the ›ON/OFF‹
›ON‹.
Disassembling your »Design Multi Juicer«
WARNING:
Always turn the appliance off and pull the
plug when the appliance is not in use or when disassembling,
moving or cleaning the appliance.
1. Ensure the appliance is turned off by pressing the ›ON/
OFF‹ switch on the control panel to ›OFF‹. Then switch the
appliance off at the power outlet and unplug the cord.
2. Remove the pulp container by tilting the pulp container
slightly to the right and unlatch it from under the juicer cover
and the container support extending from under the motor
base (picture A).
3. Use the grip handle located on the safety locking arm to lift
the locking arm from the juicer cover and lower down out of
position (picture B).
HIGH or LOW
HIGH for hard or LOW for soft
switch to
39
Speed
LOW
HIGH
LOW
LOW
LOW
LOW
A
B
