TEChNICAL DETAILS

Model:
Power Supply:
Power consumption:
Rotations:
Length of power cord:
Weight:
Dimensions: (W x D x H):
Capacity, Juice Box:
Certification:

OpERATING

Assembling the appliance
1. Place the filter bowl surround on the motorblock. Locate the filter bowl surround so that
the spout fits through the hole on the front of the motor base (picture A).
WARNING:
Handle the units with care and do not use any force. Pay attention to
2.
the sharp blades on the stainless steel micro mesh filter and the feed chute to avoid injury.
Always completely assemble your juicer before you plug the plug into the power point.
ATTENTIoN: Ensure the stainless steel filter basket is clean
before assembling. Any dehumidified left over food on the
basket will block the fine mesh holes. If necessary remove
excess fibre build up (from fruit or vegetables) according to
the instructions ›Care and Cleaning‹.
Align the arrows on the stainless steel filter basket with the
arrows on the motor drive coupling and push down until it
clicks into place. Ensure the stainless steel filter basket is fitted
securely inside the integrated pulp container and onto the
motor base (picture B).
3. Place the juicer cover over the stainless steel filter on top
of the filter bowl surround (picture C). The feed chute has to
be positioned in the middle of the filter basket and the pulp
spouting of the cover has to face away from the interlocking
safety arm.
4. Raise the safety locking arm straight up and lock into the
two grooves on either side of the juicer cover. The safety lock-
ing arm should now be in a vertical position and locked into
place on top of the juicer cover (picture D).
Important: If the safety locking arm is not in the right posi-
tion the motor will not start moving.
Art.-No. 40136 Design Juicer Pro Plus
230/240 V - 50 Hz
1.150 – 1.250 W
6.500 - 13.000 per minute
ca. 90 cm
ca. 5,98 kg
460 x 230 x 430 mm
1 Litre
36
A
B
