3.2 SVM10R Product Appearance
Receiver Antenna Probe - It can be used to receive the open/
1
short circuit signal transmitted by the SVM10T circuit finding
function.
Receiver Antenna Soft Rod - It can be bent.
2
Short Circuit Current Direction Indicator(Left)- When a short
3
circuit signal is detected and the current direction is left, it blinks.
Open Circuit Signal Indicator - It blinks when an open circuit
4
signal is detected.
Short Circuit Current Direction Indicator (Right)- When a short
5
circuit signal is detected and the current direction is right, it blinks.
Power Switch / High Sensitivity Button - Long press to turn
6
on/off, short press to increase the detection sensitivity of the
receiver.
Low Sensitivity / Lighting Button - Short press to reduce the
7
sensitivity of the receiver, long press to turn on/off the head lights.
Head Lights - For lighting.
8
4. General Description
The tool is the best electrical tester for reducing diagnostic time in all 8
to 35-volt vehicle electrical systems. After a simple hook-up of the tool to
the vehicle's battery, you can:
Determine at a glance if a circuit is positive, negative, or open without
having to reconnect clips from one battery pole to another.
Test for continuity with its built-in auxiliary ground lead.
By depressing the power switch, conduct a positive or negative battery
