EN
d) There must be at least 5CM clearance at rear side for connection and 25 CM
clearance in front to open the door and keep good air circulation.
e) Do not put anything on the top of the ice maker.
Installation clearance
top view (1:10) (mm)
To ensure proper ventilation for your ice maker, the front of the unit must be completely
unobstructed (at least 20CM free space). Allow at least 50 mm clearance at rear, and 50
mm at top and sides for proper air circulation. The installation should allow the ice maker
to be pulled forward for servicing if necessary.
When installing the ice maker under a counter, follow the recommended spacing
dimensions shown above. Place electrical and water supplies and drain fixtures in the
recommended locations as shown. Choose a well-ventilated area with temperatures
above 10 ℃ and below 32 ℃. This unit MUST be installed in an area protected from the
elements, such as wind, rain, water spray or drips.
The ice maker requires a continuous water supply with pressure 1-8 Bar as required in
above specification table. The temperature of the water feeding into the ice maker should
be between 5℃ and 25℃ for proper operation.
ELECTRICAL REQUIREMENT & CONNECTIONS
WARNING:
THIS UNIT MUST BE EARTHED.
Electrical Shock Hazard
Plug into a grounding wall outlet.
Never remove the ground prong.
Use separate power supply or receptacle.
Never use an adapter.
Never use an extension cord.
Failure to follow these instructions can result in death, fire, or
electrical shock.
Before you move your ice maker into its final location, it is important to make sure you
have the proper electrical connection.
Side view (mm)
11
40
