LA 4060CP
The service zone (S) for performing maintenance work must be freely accessible at all times.
Protection zone for installation close to walls
A 1,0 m
B 0,8 m
Protection zone for installation in a corner
A 1,0 m
B 0,8 m
C 1,5 m
!
The installation version shown on a right corner requires a protection zone of 1,5 m. This cannot be applied to a left
corner due to the positioning of the propane sensor.
Protection zone for free field installation
A
A 1,0 m
www.dimplex.eu
h
A A
h
S
h
C
h
S
h
A
h
S
0,4 m
1,0 m
A
C
0,4 m
1,0 m
0,4 m
1,0 m
452173.66.03c FD 0509
•
B
A A
A
C
S
English
A
A
EN 17
•
