• All screw connections are tight.
• Smooth running of all moving parts.
Tool required:
• Rag/cloth*
* = may not be included in the scope of delivery!
9.1 Hooking in the carrying strap (18)
(Fig. 7)
Notes:
The product may only be used with the carrying strap.
First, balance the product when the tool is switched off.
1. Put on the carrying strap (18).
2. Adjust the length of the strap so that the carabiner
hook (18a) is approx. one hand-width beneath the
right hip.
3. Attach the carabiner hook (18a) to the lifting eye (3).
4. Allow the product to settle.
Notes:
WARNING
Check the safety tab regularly before each start-up!
If necessary, the shoulder strap (18) can be quickly re-
leased from the product by pulling on the safety tab (18b).
9.2 Adjusting the guide bar (8) (Fig. 2)
1. Loosen the wing screw (9a).
2. Set the guide bar (8) to a comfortable working position
for you.
3. Retighten the wing screw (9a).
9.3 Mixing fuel (Fig. 1)
WARNING
Avoid direct skin contact with fuel and inhalation of fuel
vapours.
1. The engine must be operated with a fuel mixture of fu-
el and engine oil.
2. Use only a mixture of unleaded fuel (min. RON 95)
and special 2-stroke engine oil (JASO FD/ISO – L -
EGD).
3. Mix the fuel mixture as per the fuel mixing table.
4. Put the correct amount of fuel and 2-stroke oil into the
enclosed oil-petrol mixing bottle (17).
5. Then shake the oil-petrol mixing bottle (17) well.
9.3.1 Fuel mixture
Note:
Do not mix the fuel mixture in the tank.
Add the 2-stroke oil in accordance with the fuel mixture
table.
Fuel
0.5 litres
32 | GB
2-stroke engine oil (1:40)
12.5 ml
www.scheppach.com
9.4 Filling in fuel (Fig. 8)
DANGER
Risk of fire and explosion!
Only fill the fuel when the engine is switched off and
has cooled down. Do not smoke when refuelling the
product.
DANGER
Risk of fire and explosion!
When filling, fuel may ignite and even explode. This can
lead to severe burns or death.
Keep containers for fuel and fuel-oil mixture separate to
avoid misfuelling with normal petrol.
• Always use fresh fuel/oil mixture.
• Keep heat, flames and sparks away.
• Only fill up with fuel outdoors.
• Wear protective gloves.
• Avoid contact with skin and eyes.
• Start the product at a distance of at least 3 m from the
fuel filling point.
• Watch out for leaks. If fuel is leaking, do not start the
engine.
• Use a suitable funnel or filler pipe for refuelling so that
no fuel can spill onto the combustion engine and
housing.
Do not overfill the fuel tank!
1. Mix the fuel as described in 9.3.
2. Clean the area surrounding the filling area. Impurities
in the fuel tank (7) lead to operational faults. Shake
the oil-petrol mixture bottle (17) with the fuel mixture
again before filling it into the fuel tank (7).
3. Carefully open the tank cover (6) so that any possible
overpressure can be relieved.
4. Pour the fuel mixture into the fuel tank. Do not spill fu-
el when refuelling and do not fill the fuel tank to the
brim.
5. Always wipe up spilled fuel immediately.
6. Turn the tank cover (6) clockwise to close it.

10 Operation

The hand-held and portable petrol brush cutter has either
a thread coil or a cutting blade as a cutting device. To
protect the user, the product is fitted with a protective cov-
er that covers the cutting device.
ATTENTION
Always make sure the product is fully assembled
before commissioning!
WARNING
Please observe the legal provisions from the noise pro-
tection ordinance.
