Detaching the Rower Belt
..........................................................................................................................................................
1. To detach Belt, simply pull beyond the range of the normal
rowing stroke until the Belt detaches from the Belt bungee
pulley.
Tip: You'll hear the Velcro separating just before the Belt
detaches.
2. Unhook the Bungee Shock Cord from the Rear Brace. Then, push out the Inner Clip from the
Bungee Hook.Pull the Bungee through the Inner Clip until free. This will allow for the Bungee
Shock Cord to be threaded completely out of the Main Frame and up to the Belt Bungee Pulley
where it will be re-attached once the Rower Belt is in the proper position.
Storage Support Bracket Instructions
..........................................................................................................................................................
A Storage Support Bracket Kit for upright storage can be purchased separately.
STEP 1
Install the Z Bracket onto the Storage Base.
Note: Do not tighten the Knob and the Bolt.
Z Bracket
Storage Bracket
STEP 3
Tighten the Z Bracket Knob to fix to the Rower.
Note: Ensure the Z Bracket is Under the middle
crossbar secure
Z Bracket
Z Bracket
15
Bungee Hook
1.
2.
STEP 2
Install the Bracket onto the Rower as shown.
STEP 4
Stand the Rower up vertically with the main
frame on the floor. Using the 8mm Allen Wrench
tighten the Bolts.
Inner Clip
