Rower Box 1 & 2 Contents
..........................................................................................................................................................
3
12
11
Item Qty.
1 1 Main Frame
2 2 Left / Right Side Rail
3 1 Rower Seat
4 1 Rear Brace
9 16 M8 Washer
10 8 M8 Standard Nut
11 8 M8 Nyloc Nut
12 4 M6x15mm Bolt
13 8 M8x45mm Bolt
19 1 Storage Support Bracket
20 1 Elevate Kit
Box 1 Contents
1
4 5
13 14 15
Description
Optional Equipment (Not Included)
6
7
16 17
Item Qty.
5 1 Bungee Hook Mount
6 2 Transport Wheel Assembly
7 1 Siphon
8 1 User Guide
Hardware KIT
14 1 5mm Allen Key
15 1 6mm Allen Key
16 1 13mm Spanner
17 2 AA Battery
18 4 Water Treatment Tablet
21 1 Touch Heart Rate Handle
22 1 Smart Phone Holder
40
2 Box 2 Contents
8
18
Description
10
9
19
