Such damaged electrical connection cables must not be used and are
life-threatening due to the insulation damage.
Check the electrical connection cables for damage regularly. Make
sure that the connection cable does not hang on the power network
during the inspection.
Electrical connection cables must comply with the applicable VDE and
DIN provisions. Only use connection cables with the marking „H07RN".
The printing of the type designation on the connection cable is man-
datory.
For single-phase AC motors, we recommend a fuse rating of 16A (C)
or 16A (K) for machines with a high starting current (starting from 3000
watts)!
AC motor 230 V/ 50 Hz
Mains voltage 230 Volt / 50 Hz.
The mains connection and the extension cable have to be three-core
cables = P + N + SL. - (1/N/PE).
Extension cables must have a minimum cross-section of 1.5 mm².
Mains fuse protection is 16 A maximum.
Three-phase motor 400 V / 50 Hz
Mains voltage 400 V / 50 Hz
Mains voltage and extension cables must be 5-lead (3P + N + SL (3/N/
PE).
Extension cables must have a minimum cross-section of 1.5 mm².
Mains fuse protection is 16 A maximum.
When connecting to the mains or relocating the machine, check the di-
rection of rotation (swap polarity in the wall socket if necessary).
Turn pole inverter in the machine socket.
