Note: The level of oil must be checked when the riving knife is pulled
back. If the oil level is at the lower notch, then the oil level is at a mini-
mum. Should this be the case, oil must be immediately added.
The upper notch indicates the maximum oil level. The machine must be
on level ground. Screw in the oil dipstick fully, to measure the oil level.
Functional test
Test the function before every use.
Action:
Push both handles
towards below.
Let one handle loose,
then the other.
Let both handles loose.
Check the oil level before every use – see chapter "Maintenance".
Venting, fig. 14
Before working with the log splitter, vent the hydraulic system.
• Release the venting cap 14 by a few revolutions so the air can escape
from the oil tank.
• Leave the cap open during the operation.
• Before you move the log splitter, close the cap again in order not to
lose any oil.
If the hydraulic system is not vented, the enclosed air will damage the
gaskets and with it the complete log splitter.
Stroke limit for short logs, fig. 14
Lower splitting knife position about 10 cm above table.
• Move splitting knife to the desired position
• Release one operating arm
• Switch motor off
• Release the second operating arm
• Undo the star grip screw (10a)
46 | GB
Result:
Splitting knife goes down to approx. 10 cm
above the table.
Splitting knife stops in the desired position.
Splitting knife returns to upper position.
