If the laser (10) is no longer showing the correct cutting
line, it can be readjusted.
Tool required:
• Phillips screwdriver*
* = not included in the scope of delivery!
1. To do so, loosen the laser cover Philips screw (40)
and remove the laser cover (9). Set the laser by mov-
ing sideways until the laser beam strikes the teeth of
the saw blade (8).
2. After you have calibrated the laser (10) and fastened it
in place, fit the laser cover (9) and fasten this hand-
tight with the Philips screw for the laser cover (40).
3. The saw must be connected to the mains in order to
adjust the laser (10).
11.5 Replacing the table inlay (13)
(Fig. 1, 21)
WARNING
With a damaged table inlay there is a risk of small parts
jamming between table inlay and saw blade, blocking
the saw blade.
Immediately replace damaged table inlays!
Tool required:
• Phillips screwdriver*
* = not included in the scope of delivery!
1. Remove the Phillips screw (41) on the table inlay (13).
If necessary, rotate the rotary table (18) and angle the
saw head (6) to be able to reach the Phillips screw
(41).
2. Remove the table inlay (13).
3. Insert the new table inlay (13).
4. Tighten the Phillips screw (41) on the table inlay (13).
11.6 Brush inspection (Fig. 22)
If the product is new, check the carbon brushes after the
first 50 operating hours or if a new brush has been mount-
ed. After the initial check, check every 10 operating hours.
• If the carbon is worn down to a length of 6 mm, or the
spring or the shunt wire is burnt or damaged, both
brushes must be replaced.
• If the brushes are found to be usable after removal,
they can be reinstalled.
• To maintain the carbon brushes, open both locks anti-
clockwise. Then remove the carbon brushes.
• Re-insert the carbon brushes in reverse order.
12 Transport (Fig. 1, 4, 23)
1. Tighten the handle / locking screw for the rotary table
(14) to lock the rotary table (18).
2. Push the saw head (6) downwards and lock it with the
locking pin (34). The saw is now locked in the lower
position.
3. Fix the saw's sliding function with the locking screw
for slide rail (28a) in rear position.
4. Carry the product by the transport handle (42).
5. To reassemble the product, proceed as described in
8, 9, 10.
13 Storage
Store the product and its accessories in a dark, dry and
frost-free place that is inaccessible to children.
The optimum storage temperature is between 5°C and
30˚C.
Store the product in its original packaging.
Cover the product to protect it from dust or moisture.
Store the operating manual with the product.
14 Electrical connection
The electrical motor installed is connected and ready
for operation. The connection complies with the ap-
plicable VDE and DIN provisions. The customer's
mains connection as well as the extension cable used
must also comply with these regulations.
14.1 Important information
In the event of overloading, the motor will switch itself off.
After a cool-down period (time varies) the motor can be
switched back on again.
WARNING
The maximum permissible mains impedance Zmax of
the product is 0.443 Ω. As a user of this product, you
must determine, in consultation with the power supply
company if necessary, that the product is only connect-
ed to a supply whose impedance is less than or equal
to Zmax!
14.2 Special connection conditions
• The product fulfils the requirements of EN 61000-3-11
and is subject to special connection requirements.
This means that use at any freely selectable connec-
tion points is not permitted.
• The product can cause temporary voltage fluctuations
in unfavourable mains conditions.
• The product is intended exclusively for use at connec-
tion points which
a) do not exceed a maximum permitted mains imped-
ance "Z" (Zmax. = 0.443 Ω), or
b) have a continuous current carrying capacity of the
mains of at least 100 A per phase.
• As the user, you are required to ensure that the con-
nection point at which you wish to operate the product
fulfils one of the requirements mentioned, a) or b). If
necessary, consult with your energy supplier in this re-
gard.
14.3 Damaged electrical connection
cables
The insulation on electrical connection cables is often
damaged.
This may have the following causes:
• Pressure points, where connection cables are passed
through windows or doors,
• Kinks where the connection cable has been improper-
ly fastened or routed,
