2. The moveable stop rail (11) must be locked in a posi-
tion far enough from the inner position that the dis-
tance between the moveable stop rail (11) and the
saw blade (8) is no more than 8 mm.
3. Before making the cut, check that no collision could
occur between the moveable stop rail (11) and the
saw blade (8).
4. Tighten the set screw (23) again.
5. Move the saw head (6) to the upper position.
6. Loosen the rotary table (18) by turning the handle (14)
counter-clockwise.
7. Operate the locking lever (14a) to release the lock.
8. Tilt the saw head (18) to the left to the desired angle
using the handle (14) (see 10.6).
9. Release the locking lever (14a) to lock the locking de-
vice again.
10. Tighten the handle (14) by turning it clockwise, to fix
the rotary table (18) in place.
11. Lock the adjusting screw (15) against the table* to se-
cure the product against tipping over.
12. Loosen the locking screw (24).
13. Use the handle (1) to tilt the saw head (6) to the left to
the desired angle.
14. Retighten the locking screw (24).
15. Carry out the cut as described below 10.5.
* = may not be included in the scope of delivery!
11 Maintenance
WARNING
Pull out the mains plug before carrying out
any setting, servicing or repair work!
11.1
General maintenance tasks
• Keep protective devices, air vents and the motor
housing as free of dust and dirt as possible. Rub the
product clean with a clean cloth* or blow it off with
compressed air* at low pressure. We recommend that
you clean the product directly after every use.
• Oil all moving parts once a month.
• Clean the product at regular intervals using a damp
cloth* and a little soft soap. Do not use any cleaning
products or solvents; they could attack the plastic
parts of the product. Make sure that no water can pen-
etrate the product interior.
11.2
Replacing the saw blade (8)
(Fig. 1, 16 - 18)
WARNING
Pull out the mains plug before carrying out
any setting, servicing or repair work!
ATTENTION
Wear protective gloves when changing the
saw blade! Danger of injury!
32 | GB
Tool required:
• Allen key, 6 mm (C)
• Phillips screwdriver*
* = not included in the scope of delivery!
1. Swivel the saw head (6) upwards and lock it with the
locking pin (34).
2. Loosen the fixing screw (7a) of the cover with a Phil-
lips screwdriver.
3. Fold the saw blade guard (7) up sufficiently that the
saw blade guard (7) is above the flange screw (37).
4. With one hand, fit the 6mm Allen key (C) to the flange
screw (37).
5. Firmly press the saw shaft lock (5), and slowly turn the
flange screw (37) clockwise. After max. one turn, the
saw shaft lock (5) engages.
6. Then undo the flange screw (37), by applying a slight-
ly greater force in a clockwise direction.
7. Fully unscrew the flange screw (37) and remove the
outer flange (38).
8. Remove the saw blade (8) from the inner flange (39)
and pull it out downwards.
9. Carefully clean the flange screw (37), outer flange
(38) and inner flange (39).
10. Insert the new saw blade (8) in the reverse sequence
and tighten.
11. Fold the saw blade guard (7) downwards until the saw
blade guard (7) engages in the fixing screw (7a).
12. Re-tighten the fixing screw (7a).
ATTENTION
The cutting angle of the teeth, i.e. the direction of rota-
tion of the saw blade, must correspond to the direction
of the arrow on the housing.
13. Before continuing work, check that the safety devices
are functioning properly (Fig. 5).
ATTENTION
After each saw blade change, check that the saw blade
runs freely in the table inlay in vertical position as well
as when tilted to 45°.
ATTENTION
Changing and aligning the saw blade must be carried
out properly.
11.3
Cleaning the safety equipment of
the saw blade guard (7) (Fig. 1)
Check the saw blade guard for dirt before each start-up.
Remove old shavings and wood splinters using a brush or
similar suitable tool.
Make sure the guide bar (29) moves smoothly.
11.4
Calibrating the laser (10) (Fig. 20)
ATTENTION
Never press the ON/OFF switch when adjust-
ing the laser. Danger of injury!
