13. Table inlay
14. Handle / locking screw for rotary table
14a. Locking lever
15. Adjustment screw
16. Pointer
17. Scale
18. Rotary table
19. Fixed saw table
20. Locking screw for workpiece support
21. Workpiece support
22. Longitudinal stop
23. Set screw for the sliding stop rail
24. Locking screw
25. Clamping device
25a. Locking screw for clamping device height adjustment
25b. Knurled screw for clamping device height adjustment
25c. Locking screw for clamping device
26. Angle scale
27. Angle pointer
28. Cable routing
28a. Slide rail locking screw
29. Guide bar
30. Dust bag
31. Screw for limiting cutting depth
31a. Knurled nut for limiting cutting depth
32. Stop for cutting depth limiting
33. Tilt protection
34. Locking pin
35. Adjustment screw (90°)
35a. Locknut (90°)
36. Adjustment screw (45°)
36a. Counternut (45°)
37. Flange screw
38. Outer flange
39. Inner flange
40. Laser cover Philips screw
41. Philips screw table inlay
42. Transport handle
43. LED work light (not shown)
(Applies only to article number: 59012159953)
3 Scope of delivery (Fig. 1, 2)
Item QuantityDesignation
8. 1 x Saw blade (24 teeth)
8. 1 x Saw blade* (48 teeth)
25. 1 x Clamping device
30. 1 x Dust bag
C. 1 x Allen key, 6 mm
D. 1 x Allen key, 3 mm
1 x Sliding cross-cut mitre saw
1 x Operating manual
* = may not be included in the scope of delivery!
4 Proper use
The saw is used for the cutting of wood and plastic, ac-
cording to the machine size. The saw is not suitable for
cutting firewood.
WARNING
Do not use the product to cut materials other than those
described in the operating manual.
24 | GB
WARNING
The supplied saw blade is only intended for the sawing
of wood! Do not use this blade for sawing firewood!
Only suitable saw blades may be used for the product.
The use of any type of cutting wheels is prohibited.
The product may only be used in the intended manner.
Any use beyond this is improper. The user, not the manu-
facturer, is responsible for damages or injuries of any type
resulting from this.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instruc-
tions and operating information in the operating manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about po-
tential dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the product.
The product may only be operated with original parts and
original accessories from the manufacturer.
The safety, operating and maintenance specifications of
the manufacturer, as well as the dimensions specified in
the technical data, must be observed.
Despite use as intended, specific risk factors cannot be
entirely eliminated. Due to the design and layout of the
product, the following risks remain:
• Contact with the saw blade in the exposed sawing ar-
ea.
• Reaching into the running saw blade (cutting injury).
• Kick-back of workpieces and workpiece parts.
• Saw blade breakage.
• Ejection of faulty carbide parts of the saw blade.
• Hearing damage when the necessary hearing protec-
tion is not used.
• Harmful emissions of wood dusts during use in en-
closed areas.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
Explanation of the signal words in
the operating manual
DANGER
Signal word to indicate an imminently haz-
ardous situation which, if not avoided, will re-
sult in death or serious injury.
WARNING
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in death or serious injury.
