8.1 Checking the safety equipment of
the saw blade guard (7) (Fig. 4)
The saw blade guard protects against accidental contact
with the saw blade and against flying chips.
Check function
To do this, fold the saw down:
• The saw blade guard must expose the saw blade
when it is swung down without touching other parts.
• When the saw is folded up to the initial position, the
saw blade guard must automatically cover the saw
blade.
9 Assembly
9.1 Assembling the product
(Fig. 1, 2, 5, 6)
1. Loosen the rotary table (18) by turning the handle (14)
counter-clockwise.
2. Operate the locking lever (14a) to release the lock.
3. Use the handle (14) to adjust the rotary table (18) to
the desired angle.
4. Release the locking lever (14a) to lock the locking de-
vice again.
5. Re-tighten the handle (14) by turning it clockwise, to
fix the rotary table in place.
6. Lock the adjusting screw (15) against the table* to se-
cure the product against tipping over.
7. The saw is unlocked from the lower position by gently
pressing down on the saw head (6) and, at the same
time, pulling out the locking pin (34) from the engine
mount.
8. Turn the locking pin (34) 90 degrees to lock it in the
unlocked position.
9. Swivel the saw head (6) upwards.
10. The clamping devices (25) can be attached to both
sides of the fixed saw table (19). Insert a clamping de-
vice (25) into the bore provided for this purpose at the
rear side of the stop bar (12) and secure it by means
of the locking screw (25c).
For mitre cuts 0°- 45°, the clamping fixture (25) is to
be mounted on one side only (right) (see Fig. 11-12).
11. The saw head (6) can be tilted to the left to max. 45°
by loosening the locking screw (24).
12. The workpiece supports (21) must always be attached
and used during work.
Set the desired projection by loosening the locking
screw (20). Then retighten the locking screw (20).
* = may not be included in the scope of delivery!
9.2 Dust bag (30) (Fig. 1, 24)
The saw is equipped with a dust bag (30) for chips.
Squeeze the wings of the metal ring on the dust bag (30)
together and slide it over the discharge port near the mo-
tor. The dust bag (30) can be emptied via the zip on the
underside.
9.2.1 Connection to an external dust
extraction system
1. Connect the suction hose to the dust extraction.
2. The dust extraction system must be suitable for the
material to be processed.
3. Use a special extraction device to extract dusts that
are particularly harmful to health or carcinogenic.
9.3 Fine adjustment of the stop for 90°
chop cut (Fig. 1, 7)
Tool required:
• Allen key, 6 mm (C)
• 90° engineers square (A)*
• Phillips screwdriver*
• Open-ended spanner, size 13 mm*
* = not included in the scope of delivery!
1. Lower the saw head (6) and fix it with the locking pin
(34).
2. Loosen the locking screw (24).
3. Place 90° engineers square (A) between saw blade
(8) and rotary table (18).
4. Loosen the locknut (35a).
5. Adjust the adjustment screw (35) until the angle be-
tween the saw blade (8) and the rotary table (18) is
90°.
6. Re-tighten the locknut (35a).
7. Then check the position of the angle display. If neces-
sary, loosen the pointer (16) with a Phillips screw-
driver, set the scale (17) to 0° position and re-tighten.
9.4 Fine adjustment of the stop for 45°
mitre cut (Fig. 1, 8)
Tool required:
• 45° engineers square (B)*
• Open-ended spanner, size 13 mm*
• Phillips screwdriver*
* = may not be included in the scope of delivery!
1. Lower the saw head (6) and fix it with the locking pin
(34).
2. Fix the rotary table (18) in the 0° position.
ATTENTION
For mitre cuts (inclined saw head), the moveable stop
rail must be fixed in the outer position (left side).
3. Loosen the locking screw (23) on the moveable stop
rails (11) and slide the sliding stop rails (11) outwards
to create a 45° stop angle (B) between the saw blade
(8) and the rotary table (18).
4. The moveable stop rails (11) must be locked in a posi-
tion that the distance between the stop rails (11) and
the saw blade (8) is at least 8 mm.
5. The sliding stop rail (11) must be in the inner position
(right side).
6. Before making the cut, check that no collision could
occur between the moveable stop rails (11) and the
saw blade (8).
7. Loosen the locking screw (24) and tilt the saw head
(6) to the left, to 45°, using the handle (14).
