Behncke Basic I Betriebsanleitung Seite 26

Behncke Basic I + II / Temperature control
6 Temperature control
The electronic temperature control and the temperature sensor are synchronised to each other.
If the sensor or the control unit are replaced individually, a new adjustment must be carried out with an
adjustment controller on the motherboard.
If the water temperature does not correspond to the desired temperature due to an unfavourable
installation location of the temperature sensor, this can also be readjusted with the setting controller.
The temperature sensor is supplied as standard with a cable length of 2m.
If required (cross-section min. 0.34mm²), this can be extended up to a maximum of 20m
(specialist personnel only).
7 Replacement parts
391 028 03 Suevia "Practic D" timer
391 187 50 Empty housing for filter control system
555 007 52 Self-sealing grommet EPN 470/M16
555 007 44 Locknut EPN 355 / M 16
7.1 230V without temperature control
555 000 76 Hot box detector switch, black
555 004 84 Front panel for filter control system 230V without temperature control
7.2 230V with temperature control
391 187 31 Circuit board with sensor and temp. control, compl.
391 187 32 PTC sensor for filter control system with 2m cable
Front panel for filter control system
555 004 83
9
Resistance values
0°C
10°C
20°C
25°C
30°C
NOTE
Avoid laying the sensor cable close to mains cables to avoid possible
interference.
NOTE
As exact temperature control is only possible with good heat transfer between
the temperature sensor and the swimming pool water, an "immersion pocket
R1/2" (item no. 390 333 33) must be installed in the piping system.
1,645 ohms
1782 ohms
1925 ohms
2000 ohms
2075 ohms
