Adjusting the stay rod clamp
Position Diameter of the stay rod
1 Diameter 40 to 45 mm
2 Diameter 45 to 53 mm
3 Diameter 53 to 60 mm
POSITION 1
PXCP-KIT: CENTRING KIT
POSITION 2
PXCP-10 : 10 mm centring rod
PXCP-12 : 12 mm centring rod
PXCP-24 : 14 mm centring rod
PXCP-26 : 14 mm centring device
POSITION 3
