I. Description of the X'COMP® I. Description of the X'COMP®
The X'COMP® is a tool designed for installing and removing is a tool designed for installing and removing
McPherson-type stay rods. To avoid any malfunctioning, McPherson-type stay rods. To avoid any malfunctioning,
it is essential that the lubricated compressed air circuit should it is essential that the lubricated compressed air circuit should
be at a pressure comprised between 6.5 and 10 bar max. be at a pressure comprised between 6.5 and 10 bar max.
Stay rod clamp used to maintain the shock absorber in place Stay rod clamp used to maintain the shock absorber in place
in the machine. Safety hatch present at the level of the upper in the machine. Safety hatch present at the level of the upper
hole in the door.
Tool storage container on the top of the machine.
Connection of the equipment to the air network on the machine Connection of the equipment to the air network on the machine
side, take care to check its correct connection to the network. side, take care to check its correct connection to the network.
Cylinder used to replace shock absorbers on vehicles weighing Cylinder used to replace shock absorbers on vehicles weighing
up to 4.5T.
The machine must be locked out/tagged out with a padlock The machine must be locked out/tagged out with a padlock
in the case of any malfunctioning or any long
period of non-use.
II. Technical characteristics II. Technical characteristics
Desigantion
Compression force :
Operating pressure :
Cylinder stroke :
Compliance :
Machine dimensions :
Machine weight :
III. Unpacking the equipment
PPE must obligatorily be worn when handling the equipment and you are advised to strap up the device.
The X'COMP® is delivered attached to a wooden pallet. Position the pallet in the place where you want to install the equipment then remove
the cardboard packaging. Use a forklift truck with adjustable forks to lower the equipment from the pallet. Unscrew the X'COMP® from the pallet.
Turn over the attachment lugs so you can lift the X'COMP®. Place the truck's forks against the walls of the X'COMP® and under the attachment lugs.
Lift the X'COMP® by about 2 centimetres and move it to the place where you want to install it.
Lastly, turn over the X'COMP®'s attachment lugs.
If you do not have a forklift truck, proceed as follows: Two people are required to remove the equipment from the pallet. Tilt the X'COMP®
to one side by gripping the upper part of the equipment while sliding it until the lower part protrudes beyond the pallet and touches the fl oor.
Remove the pallet and position the equipment in the place where you want to install it.
THE CARDBOARD PACKAGING MUST BE DISPOSED OF IN A PLACE PROVIDED FOR THAT PURPOSE,
AND YOU ARE ADVISED TO KEEP THE PACKAGING OUT OF THE REACH OF CHILDREN.
18 / 124
Value
4,5 tonnes
6,5 à 10 bars
360 mm
2006/42/CE
453,3 x 677,8 x 1595,5 mm 453,3 x 677,8 x 1595,5 mm
115 kg
