11. Technical data
AQA total Mod.
Connection diameter DN
Connection outside-thread
Treatment output
max. simultaneous
Residential units
No. of cartridges
Capacity per cartridge
Treatment capacity total
Pressure drop at nominal flow rate
Nominal pressure/operating pressure
Water hardness max.
Max. water temperature
Ambient temperature
Max. boiler temperature
Unit height total
Unit width
Operating weight
Mains connection
Protection class
Electrical connection output
Energy consumption
Output in standby operation
34
5600 8400 11200
[mm] 40 40 50
[inch] 6/4" 6/4" 2"
[l/min] 93 140 187
[m 3 /h] 5,6 8,4 11,2
5-8 RU 9-16 RU 17-28 RU
[amount] 2 3 4
[m ] 575±25 575±25 575±25
3
[m 3 ] 1150±50 1725±75 2300±100
[bar] 0,8 0,8 0,8
[bar] 2 / 10 2 / 10 2 / 10
[°dH/ppm] 25/445 25/445 25/445
[°C/°F] 30/86 30/86 30/86
[°C/°F] 40/104 40/104 40/104
[°C/°F] 80/176 80/176 80/176
[mm] 1280 1280 1280
[mm] 560 560 825
[kg/lb] 57/126 64/141 94/207
[V/Hz] 230/50 230/50 230/50
IP 54 IP 54 IP 54
[W] 120 180 240
[kWh/m 3 ] 0,055 0,055 0,055
[Wh] 13 13 15
