Implement the reset procedure:
I. Disconnect the mains plug
and wait approx. 5 – 10
seconds.
II. Reconnect the display mains
plug while keeping the reset
button pressed down (+).
III. Only let the (+) button go when standby
appears on the display.
standby
Channel 1 2 3 4 5
IV. If the yellow lamp on the slave lights up or fla-
shes after the refill replacement, a system er-
ror is probably present. Rectify the error as
follows:
1. Enter the code key:
Press the "M" button to switch to the mode whe-
re settings can be made in the electronic control
system. You will be requested to enter the code.
Press the "C" button so that you can enter the
code.
Code (-key) M ←
000 ok = - (+/c)
Use the "+" button to change the value of each
number in the 3 digit numerical code. Use the "C"
button to move to the next number in the 3 digit
numerical code.
Code M ←
369 ok = - (+/c)
The 3 digit numerical code is: 369
Confirm your entry with the "-" key.
The numerical code authorizes you to change set-
tings in the AQA total unit. Please remember that
incorrect settings can reduce the performance of
the unit. The code should therefore be stored sa-
fely and protected against unauthorized access.
V. Menu control
Use the "-" button to go forward in the menu
or the "M" button to go back.
30
After the refill replacement (usually, all of them),
this action must be confirmed to the electronic
control system.
I. Navigate through the menu until the fol-
lowing text appears in the LC display:
Refill ← M-→
II. Press the "C" button
Refill(s) ← M-→
all =C
III. Use the "+" button to select which refill was
replaced. Normally all refills are replaced.
IV. Confirm the refill replacement with the "C"
button.
V. After a moment, the unit switches back to the
operating mode and is fully functional.
Display on standby or operation goes out.
If the red „Check System" lamp does not go out
after commissioning or if the green „Operation"
lamp does not light up during water consumption,
a system error is given.
7.2. Regular maintenance/service by
trained personnel
The system must be maintained by trained per-
sonnel at regular intervals (a six months interval is
recommended) to ensure functionality of the sys-
tem. We recommend you to have a maintenance
contract with our customer services or with your
expert installer.
8. Operation
8.1. Operation hardly required
During operation, the AQA total unit does not need
operating (apart from the refill replacement).
The unit adapts itself to the water properties by
means of the electronic control system.
8.2. Implementing setting
The following settings in the electronic control
system can be modified/input:
- Changing the operating language
- Changing the polarity times
- Confirm refill replacement
- Reset to default settings
In order to change settings in the electronic
control system, proceed as follows:
I. Open the control box.
II. The LCD in the control box will display:
standby
Channel 1 2 3 4 5
or the number of cartridges according to the
unit type.
Use the buttons below the LCD to implement
changes in the control system.
The settings are protected against unauthorized
access by a code that must be input.
Operating keys
III. Input code
Press the "M" button to switch to the mode whe-
re settings can be made in the electronic control
system. You will be requested to enter the code.
Press the "C" button so that you can enter the
code.
Code (-key) M ←
000 ok = - (+/c)
Use the "+" button to change the value of each
number in the 3 digit numerical code. Use the "C"
button to move to the next number in the 3 digit
numerical code.
Code M ←
369 ok = - (+/c)
The 3 digit numerical code is: 369
Confirm your entry with the "-" key.
The numerical code authorizes you to change
settings in the AQA total unit. Please remember
that incorrect settings can reduce the perfor-
mance of the unit. The code should there- fore
be stored safely and protected against unautho-
rized access.
IV.) Menu control
Use the "-" button to go forward in the menu or
the "M" button to go back.
Back to
numerical
code Input:
8.2.1. Change of language
Changing the operating language
The following languages are available:
English, French, Spanish, Italian, German
I. Navigate as described above until the fol
lowing text appears in the LC display:
language (+)
German ← M-→
II. Use the "+" button to select the language.
III. Confirm the entry by pressing the "M" button
twice.
